11.1 (2 or 3X) Hydraulic Tank - Valve Body Group

18
ITEM # PART NUMBER
1 600.2401
2
800.2005
3 SCL.5CT1214
4 800.2003
800.2004
5
6
7
*Hose*
8 STD.9057
550.1700B
9
10
11
*Hose*
ODB COMPANY
LCT600 / 6000 multi-axis units - January 2006 and after
2
3
*2 Station
2 axis
8
16
19
DESCRIPTION
Hydraulic Tank
Filler Cap
Site Guage
Hydraulic Filter Assembly
Filter Only
90 Degree Fitting To Tank
90 Degree Fitting
Hydraulic Hose, 1/2"
Valve Body 2 Section
Valve Body 4 Section
90 Degree Fitting
90 Degree Fitting
Hydraulic Hose, 1/2"
1
6
5
8
17
12
9
15
Notes: All hydraulic hoses and wiring harness are special and
have to be made up to fit the particular application.
ITEM # PART NUMBER
12 *Hose*
13
STD.9015
650.142
14
15
Varies
16 Varies
17
18 800.950
800.900
19 800.952
800-446-9823
4
14
7
*4 Station
3 axis
10
11
DESCRIPTION
Hydraulic Hose, 1/2"
Hydraulic Pump, Double
Valve
Hydraulic Pump, Single Valve
90 Degree Fitting
Wiring Harness to Valve Body
Wiring Harness To Joystick
Fitting To Tank
Fitting to tank
Joystick Assembly, Single
Joystick Assembly, Dual
Single Joystick Holder
13
116
LCT6000
