Exhuast Duct Assembly - ODB LCT6000 Owner's Manual

#5,#6 and #7 do not come as standard equipment
To mount #5, Item #6 is required for all units built after Feb. 2001
18" DIAMETER
(STANDARD)
ITEM # PART NUMBER
1
LCT631.610
2 LCT631.611A
LCT631.611
3
LCT616.618
4 LC-MDH.18.72
5
LCT60.629B
6 **LCT60.629BCL
7 N/A
*Note: the 16" column is for 6000 units that have a 16" diameter exhaust only.
**Note: Item #6 fits 6" x 4" (6000) tow bars only.
ODB COMPANY

8.5 Exhuast Duct Assembly

LCT6000 after February 2001
1
7
2
*16" DIAMETER
(OPTIONAL)
PART NUMBER
LCT621.610
LCT630.629
LCT621.611A
LCT616.616
LC-MDH.16.48
LCT60.629A
**LCT60.629BCL
LCT631.621
3
5
6
DESCRIPTION
Discharge Duct
Transition, 49" Long(18"),61"L(16")
Transition, 43" Long(18"),43"L(16")
Hose Band
Exhaust Hose,5'L(18"), 4'L(16")
Exhaust Hose Support (OPTIONAL)
Hose Support Clamp (OPTIONAL)
18" to 16" Rectangular Transition
800-446-9823
4
102
LCT6000
