Axis) Boom Assembly - ODB LCT6000 Owner's Manual

6
8
16" Diameter Setup,
18" will be different - please verify
*All units are custom made, use numbers as a reference only.
ITEM # PART NO.
1 800.707B
2 LCT616.606MA.3
LCT616.606MA.4
3 SCL816.812
4 800.704B
5 800.701D
6 Call
7 LCT622.635
8 LCT616.601.90MA 90 Degree Nozzle
ODB COMPANY

11.3 (2 Axis) Boom Assembly

2010 thru present)
(
7 7
9
6
DESCRIPTION
Boom Mast
Boom Arm, 2 Axis when
using 90 degree nozzle
Boom Arm, 2 axis when
using standard nozzle
Boom Cylinder
Auburn Gear
Hydraulic Motor
Chain
Boom Hanger Bracket
2
16 16
14
18
3
10
ITEM # PART NO.
9 LCT616.616
10 LCT616.603U
11 Varies, please call
12 800.708
13 800.710
14 800.712
15 800.709
16 8X.002E
17 800.609
18 HYF.1028.M
800-446-9823
4
16 16
15
16 16
14 14
17
9
11
DESCRIPTION
Hose Clamp
Hose Support
Intake Hose
Bolt, 3/4-16 x 4.5" Long
Bolt, 3/4-16 x 7.5" Long
Nut, 3/4"
Bolt, 3/4-16 x 5" Long
Bushing, .75"x.375ODx1
Bearing
Fitting, 90 degree swivel
LCT6000
