Operating Guide | VACON® NX Inverters FI4-FI8
A
A The clearance around the drive (see also B and C)
C The free space above the drive
Illustration 11: Installation Space
Table 6: Minimum Clearances around the AC Drive in mm (in inch)
Drive type
0004 5-0012 5
0016 5-0048 5
0004 6-0034 6
0061 5-0105 5
0041 6-0052 6
Danfoss A/S © 2019.07
B
A
A
20
(0.79)
30
(1.18)
80
(3.15)
B
B The distance from a drive to a second drive, or the distance to
the cabinet wall
D The free space below the drive
B C
20 100
(0.79) (3.94)
20 160
(0.79) (6.30)
80 300
(3.15) (11.81)
Mounting the Unit
D
50
(1.97)
80
(3.15)
100
(3.94)
