Operating Guide | VACON® NX Inverters FI4-FI8
Code Description
NXI The product range:
• NXI = VACON
0003 The drive rating in amperes. For example, 0003 = 3 A
5 The mains voltage:
• 5 = 380–500 V
• 6 = 525–690 V (IEC)
A The control panel:
• A = standard (text display)
• B = no local control panel
• F = dummy keypad
• G = graphical display
2 The protection rating:
• 0 = IP00
• 2 = IP21 (UL Type 1)
• 5 = IP54 (UL Type 12)
T The EMC emission level:
• T = complies with the standard IEC/EN 61800-3 + A1 when used in IT networks (C4).
0
The brake chopper:
• 0 = No brake chopper
SSS The hardware changes:
• The supply, the first letter (Xxx):
-
-
-
-
-
• The mounting, the second letter: (xXx):
-
-
• The boards, the third letter (xxX):
-
-
-
-
Danfoss A/S © 2019.07
®
NX Inverter
(1)
C = INU - with integrated charging circuit
I = INU - no charging circuit
2 = AFE module
5 = AFE module + LCL filter
8 = BCU brake chopper unit
S = Standard air cooled drive
U = Standard air cooled power unit - external supply for main fan
S = Direct connection, standard boards, FI4-FI8
V = Direct connection, varnished boards, FI4-FI8
F= Fiber connection, standard boards
G = Fiber connection, varnished boards
Product Overview
