Operating Guide | VACON® NX Inverters FI4-FI8
The control panel constitutes a link between the user and the inverter. The control panel is used for parameter setting, reading status
data and giving control commands. It is detachable and can be operated externally and is connected via a cable to the inverter. Instead
of the control panel, a PC can be used to control the inverter when connected through a similar cable (VACON
The basic control interface and the parameters (the Basic Application) are easy to use. If a more versatile interface or parameters are
required, a more suitable application can be selected from the "All in One" Application Package. See the "All in One" Application
Manual for more information on the different applications.
Optional I/O expander boards that increase the number of inputs and outputs to be used are also available. For more information,
contact the Manufacturer or your local distributor.
3.2 Intended Use
The drive is an electronic motor controller intended for:
•
Regulation of motor speed in response to system feedback or to remote commands from external controllers. A power drive
system consists of the AC drive, the motor, and equipment driven by the motor.
•
System and motor status surveillance.
The drive can also be used for motor overload protection.
Depending on the configuration, the drive can be used in standalone applications or form part of a larger appliance or installation.
The drive is allowed for use in residential, industrial, and commercial environments in accordance with local laws and standards.
In a residential environment, this product can cause radio interference, in which case supplementary mitigation measures can
be required.
Foreseeable misuse
Do not use the drive in applications which are non-compliant with specified operating conditions and environments. Ensure
compliance with the conditions specified in
3.3 Manual Version
This manual is regularly reviewed and updated. All suggestions for improvement are welcome.
The original language of this manual is English.
Table 1: Manual and Software Version
Edition
DPD00908D
16 | Danfoss A/S © 2019.07
N O T I C E
12.8 Technical
Data.
Remarks
Structure of the manual changed.
Product Overview
®
RS232PC –1.5M).
AQ299433367205en-000101 / DPD00908
