Operating Guide | VACON® NX Inverters FI4-FI8
Procedure
1. Strip the DC supply cable, the mains cable, and the brake resistor cable. See
2. Cut the grommets open to move the cables through them. Use the grommets delivered in the accessories bag.
• Do not cut the grommet openings wider than what is necessary for the used cables.
• If the grommets fold in when putting the cable, pull the cable back to make the grommets straight.
• Use a cable gland as an alternative to the grommet in types where this is necessary.
3. Put the cables - the DC supply cable, the motor cable, and the optional brake cable - in the openings of the cable entry plate. Use
the cable entry plate delivered in the accessories bag.
A
B
A The DC supply cable
C The motor cable
Illustration 18:
4. Put the cable entry plate with the cables into the groove on the frame of the drive. To attach the cable entry plate, use the M4x10
screws delivered in the accessories bag.
50 | Danfoss A/S © 2019.07
C
Cables through the Cable Entry Plate
12.4 Cable Stripping Lengths.
B The brake cable
AQ299433367205en-000101 / DPD00908
Electrical Installation
