Operating Guide | VACON® NX Inverters FI4-FI8
12.2.3 Dimensions for Flange Mounting, FI7–FI8
W4
W2
Illustration 41: Dimensions of the VACON
Table 21: Dimensions in mm (in inch) of the VACON
Drive type
0061 5–0105 5
0041 6–0052 6
0140 5
0062 6–0100 6
Table 22: Dimensions in mm (in inch) of the VACON
Drive type
0061 5–0105 5
0041 6–0052 6
0140 5
0062 6–0100 6
112 | Danfoss A/S © 2019.07
Ø
H6
®
NX Inverters with Flange, FI7 and FI8
®
NX Inverters with Flange, FI7 and FI8, part 1
W1 W2
237 175
(9.33) (6.89)
285 –
(29.72) (–)
®
NX Inverters, FI7 and FI8, part 2
H1 H2
652 632
(25.67) (24.88)
755 –
(29.72) (–)
H3
W3
W1
IP21
W3 W4
270 253
(10.63) (9.96)
355 330
(13.98) (12.99)
H3 H4
630 188.5
(24.80) (7.42)
745 258
(29.33) (10.16)
Specifications
H7
W3
W1
IP54
D1 D2
257 117
(10.12) (4.61)
288 110
(11.34) (4.33)
H5 H6
188.5 23
(7.42) (0.91)
265 43
(10.43) (1.69)
AQ299433367205en-000101 / DPD00908
Ø
5.5
(0.22)
9
(0.35)
H7
20
(0.79)
57
(2.24)
