rBOX510-6COM User's Manual
 Embedded O.S. Supported
rBOX510 not only supports Windows
embedded OS, such as W indows
Linux package support. For storage device, rBOX510 supports one SATA SSD
(or HDD) and one type II CompactFlash
1.2

System Specifications

1.2.1

CPU

®
ATOM™ E3827 (1.75 GHz) or E3845 (1.91 GHz) processor.
 Onboard Intel
1.2.2

BIOS

 AMI (American Megatrends Inc.) UEFI (Unified Extensible Firmware Interface)
BIOS.
1.2.3

System Memory

 Memory down solution w/extended temperature memory chip
 Memory size 4GB onboard
1.2.4

Display

 A slim type 15-pin D-Sub connector as VGA connector.
1.2.5

Ethernet Ports

 LAN 1 and LAN 2
The board has dual RJ-45 connectors, support 10/100/1000Mbps with 1.5KV
magnetic isolated protection.
 Support PXE boot and LAN wake-up
1.2.6

Storages

2.5" SATA SSD/HDD drive bay
 1 x
selectable )
 1 x CompactFlash TypeII socket
Note: mSATA and SATA SSD (or HDD) can be either one.
Note: mSATA and wireless use the same slot, and only one of them can be selected.
2
®
7 and Windows
®
7 embedded, W indows
™
socket.
(default) or 1 x mSATA socket (by BIOS
®
8, but also supports
®
8 embedded and
Introduction
