rBOX104-FL Quick Installation Guide
I.
Packing List
rBOX104-FL System
Unit x 1
rBOX104-FL Quick
Installation Guide x 1
Screws
Power terminal block
II.
Dimensions
©Copyright 2011 AXIOMTEK Co., Ltd.
Version A1 January 2011
Printed in Taiwan
9416M104010E
CD x 1 (for Driver and User's
Manual)
Din-rail Kit x1
GMA-500 VGA Hot Key
Notice x1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AXIOMTEK rBOX104-FL
Summary of Contents for AXIOMTEK rBOX104-FL
- Page 1 Quick Installation Guide Packing List rBOX104-FL System CD x 1 (for Driver and User’s Unit x 1 Manual) rBOX104-FL Quick Din-rail Kit x1 Installation Guide x 1 GMA-500 VGA Hot Key Screws Notice x1 Power terminal block Dimensions ©Copyright 2011 AXIOMTEK Co., Ltd.
-
Page 2: Top View
Quick Installation Guide III. I/O Outlets The following figures show you I/O outlets on front view and top view of the rBOX104-FL. Front View LAN 1 4-Port PoE COM 1/2 Top View DC Power Input w/ terminal block RESET ©... - Page 3 Quick Installation Guide Installing the Memory Module Step 1 Turn off the system. Step 2 Loosen these screws, and remove the top cover from the system. Step 3 Hold one side of the module, and insert the gold colored contact into the socket.
- Page 4 Quick Installation Guide Installing the CompactFlash™ Card Step 1 Turn off the system. Step 2 Loosen these screws, and remove the cover from the system. Step 3 Loosen these screws and remove the Thermal & CompactFlash fixing bracket from the system.
