1.2.14

System LED


There are showed the LED's indicators and functional descriptions.
LED Name
Indicate the Power status.
- LED will be on for green color when the power DC input is
PWR
acceptable.
- LED will be on for red color when the power DC input isn't
acceptable or power fail event.
The LED for ACT can help user's to judge BIOS finish or not
and the OS can normal work or not.
- LED will ON for red color when the power DC input is system
active
- LED will flash for red color when the BIOS start
- LED will ON for green color when enter OS status.
ACT
- LED will flash for green color when the storage is
accessed.
- LED always ON without any flash for a long time, the OS
is possible crashed.
- LED is off when system shutdown status
Indicate the Wireless status.
Wireless
- When ANT accessed data the LED will flash.
COM TX1
COM RX1
COM TX2
COM RX2
COM TX3
COM RX3
COM TX4
COM RX4
COM TX5
COM RX5
COM TX6
COM RX6
Introduction
Description
When COM1 transmit data the LED will on.
When COM1 receive data the LED will on.
When COM2 transmit data the LED will on.
When COM2 receive data the LED will on.
When COM3 transmit data the LED will on.
When COM3 receive data the LED will on.
When COM4 transmit data the LED will on.
When COM4 receive data the LED will on.
When COM5 transmit data the LED will on.
When COM5 receive data the LED will on.
When COM6 transmit data the LED will on.
When COM6 receive data the LED will on.
rBOX510-6COM User's Manual
Color
Green
Red
Green
Red
Green
Green
Yellow
Green
Yellow
Green
Yellow
Green
Yellow
Green
Yellow
Green
Yellow
