Summary of Contents for AXIOMTEK GOT817-834

  • Page 1 GOT817-834 17” SXGA TFT Touch Panel Computer User’s Manual IP69K certification distinguishes the highest level of reliability...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice.

  • Page 3: Safety Precautions

    Turn OFF the system power before cleaning. Clean the system using a cloth only. Do not spray any liquid cleaner directly onto the screen. The GOT817-834 may come with or w/o a touchscreen. Although the touchscreen is chemical resistant, it is recommended that you spray the liquid cleaner on a cloth first before wiping the screen.

  • Page 4: Table Of Contents

    USB Port ......................10 2.1.4 DC Power Jack w/ M12 connector ..............10 Water-proof Cables ..............11 2.2.1 Power cable ...................... 11 2.2.2 Power adapter for GOT817-834 ............... 12 2.2.3 COM ........................12 2.2.4 USB cables ....................... 13 Mounting Method ..............13 2.3.1 VESA mounting ....................
  • Page 5 4.2.1 Specification ...................... 35 4.2.2 Driver Installation- Windows 7/8.x ..............35 Embedded O.S................37 4.3.1 WES 7 & WE8S ....................37...
  • Page 6 This page is intentionally left blank.

  • Page 7: Chapter 1 Introduction

     Dimensions  I/O Outlets  Package List General Description The GOT817-834 is a fan-less and compact-size touch panel computer, equipped with a 17” ○ SXGA TFT LCD display and low power consumption Intel Atom E3827 1.75GHz processor. ® ®...

  • Page 8: Specifications

    GOT817-834 User’s Manual Specifications 1.2.1 Main CPU Board  ®  Intel Atom E3827 1.75GHz processor onboard  System Memory  One 204-pin DDR3L(1.35V) SO-DIMM socket  Maximum memory up to 8GB  BIOS  America Megatrends BIOS  Power ...

  • Page 9: System Specification

    5 to 500 Hz, 2.0 G for CFast or mSATA  5 to 500 Hz, 2.0 G for SSD 1. All specifications and images are subject to change without notice. 2. The GOT817-834 is suited on serious environment; please choose the wide temperature DRAM and SSD. Note ℃...

  • Page 10: Dimensions

    GOT817-834 User’s Manual Dimensions This diagram shows you dimensions and outlines of the GOT817-834. Introduction...

  • Page 11: I/O Outlets

    GOT817-834 User’s Manual I/O Outlets Please refer to the following illustration for I/O locations of the GOT817-834. Function Backlight ON/OFF Brightness Adjust Power Switch(ATX) DC power connector (A-coded) COM1(configure RS422/485, default RS-232, A-coded) COM2(configure RS422/485, default RS-232, A-coded) Ethernet (X-coded) USB2.0 ×...

  • Page 12: Antenna Installation (Optional)

    GOT817-834 User’s Manual Antenna installation (optional) If you have the optional wireless module, you will find the antenna in the accessory box. The installation instructions are as follows 1. If you add optional 2T2R W IFI module, the ANT1 is MAIN wifi antenna, the ANT2 is AUX wifi antenna.

  • Page 13: Package List

     Water-proof Power / USB / LAN / RS-232 cables (optional)  Water-proof Antenna for Wifi or UMTS/HSPA+ (optional)  VESA ARM(optional) If you can not find the package or any items are missing, please contact Axiomtek distributors immediately. Introduction...
  • Page 14 GOT817-834 User’s Manual This page is intentionally left blank. Introduction...

  • Page 15: Chapter 2 System Configurations

    GOT815-834 User’s Manual CHAPTER 2 System Configurations The GOT817-834 provides rich I/O ports and flexible expansions for you to meet different demand, for example, CF. The chapter will show you how to install the hardware. It includes:  I/O Pin Assignment ...

  • Page 16: Ethernet

    GOT817-834 User’s Manual 2.1.2 Ethernet The GOT817-834 is equipped with a high performance Plug and Play Ethernet interface, full compliant with IEEE 802.3 standard, and can be connected with a M12 X-CODE LAN connector. Please refer to detailed pin assignment list below:...

  • Page 17: Water-Proof Cables

    GOT815-834 User’s Manual Water-proof Cables GOT-800 series uses specific M12 connector for water-proof. Therefore you will order each cable base on application. There are four kind cables of GOT817, by the optional, if you will apply the USB, COM or Etherent then you can select a cable for the package.

  • Page 18: Power Adapter For Got817-834

    GOT817-834 User’s Manual 2.2.2 Power adapter for GOT817-834 If you order the power adapter, you should choose the power cord type for your location. The power adapter is +24VDC(70W), 110-240V which is combined M12 connector. 2.2.3 COM There are two COM cables which are combined M12 connector. Also, you can refer 2.1.1 for the Series port pin assignement.

  • Page 19: Usb Cables

    The USB cable is combined M12 connector for water-proof. It is extended two USB ports for applicaton. Mounting Method There are two mounting ways for the GOT817-834. One is suspension, the other is VESA mount. 2.3.1 VESA mounting The GOT817 can accept VESA 100.

  • Page 20: Vesa-Arm Mounting

    GOT817-834 User’s Manual 2.3.2 VESA-ARM Mounting Step 1 Find out the 4 screws as marked on the back side of chassis. Step 2 Assemble the VESA-ARM to the back side of the chassis, and fix the screws. Step 3 VESA mounting Installation completed.

  • Page 21: Chapter 3 Ami Bios Setup Utility

    GOT815-834 User’s Manual CHAPTER 3 AMI BIOS Setup Utility This chapter provides users with detailed description how to set up basic system configuration through the AMIBIOS8 BIOS setup utility. Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process.

  • Page 22: Main Menu

    GOT817-834 User’s Manual Main Menu System Time/Date Use this option to change the system time and date. Highlight System Time or System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time is entered in HH:MM:SS format.

  • Page 23: Advanced Menu

    GOT815-834 User’s Manual Advanced Menu The Advanced menu allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ...
  • Page 24 GOT817-834 User’s Manual ACPI Sleep State Allow you to select the Advanced Configuration and Power Interface (ACPI) state to be used for system suspend. Here are the options for your selection, Suspend disable and S3 (Suspend to RAM). AMI BIOS Setup Utility...
  • Page 25 GOT815-834 User’s Manual  NCT6106D Super IO Configuration Use this screen to select options for the Super IO Configuration, and change the value of the selected option Serial Port 1-2configuration Serial port: This option used to enable or disable the serial port. Device Setting: This item specifies the base I/O port address and Interrupt Request address of serial port.
  • Page 26 GOT817-834 User’s Manual  Serial type This option used to select RS232/422/485 function. AMI BIOS Setup Utility...
  • Page 27 GOT815-834 User’s Manual  NCT6106D H/W Monitor This screen shows the Hardware Health Configuration. AMI BIOS Setup Utility...
  • Page 28 GOT817-834 User’s Manual  CPU Configuration This screen shows the CPU Configuration and Intel virtualization technology enable/disable selected AMI BIOS Setup Utility...
  • Page 29 GOT815-834 User’s Manual  IDE Configuration You can use this screen to select options for the SATA Configuration, and change the value of the selected option.  SATA Mode Use this item to choose the SATA operation mode. Here are the options for your selection, IDE Mode, AHCI Mode.
  • Page 30 GOT817-834 User’s Manual  LPSS & SCC Configuration You can select any of the items in the frame of the screen to change the OS, the default setting is W in 7. Please be informed to select the Windows 8.x when installing Win 8 or Win 8.1.
  • Page 31 GOT815-834 User’s Manual  Intel TXE Configuration The Advanced menu allows users to update the TXE firmware. AMI BIOS Setup Utility...

  • Page 32: Chipset Menu

    GOT817-834 User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. AMI BIOS Setup Utility...
  • Page 33 GOT815-834 User’s Manual  North Bridge This screen shows the North Bridge memory information. AMI BIOS Setup Utility...
  • Page 34 GOT817-834 User’s Manual  South Bridge AMI BIOS Setup Utility...
  • Page 35 GOT815-834 User’s Manual  USB Configuration You can use this screen to select options for the USB Configuration. If USB3.0 function used, XHCI Mode must disable and EHCI must enable. Suggest that don’t adjust the items if not necessary. Note AMI BIOS Setup Utility...

  • Page 36: Security

    GOT817-834 User’s Manual Security AMI BIOS Setup Utility...

  • Page 37: Boot Menu

    GOT815-834 User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus: Setup Prompt Timeout Set the Timeout for wait press key to enter Setup Menu.

  • Page 38: Save&Exit

    GOT817-834 User’s Manual Save&Exit AMI BIOS Setup Utility...

  • Page 39: Chapter 4 Drivers Installation

    GOT815-834 User’s Manual CHAPTER 4 Drivers Installation System GOT817-834 supports W indows 7, W indows 8/8.1,W ES 7 and W E8S. To facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. 4.1.1 Win 7 Insert Driver CD and select the “\Drivers”.

  • Page 40: Win 8/8.X

    GOT817-834 User’s Manual 4.1.2 Win 8/8.x Insert Driver CD and select the “\Drivers”. Select all files and follow the installing procedure. If you didn’t install graphics driver, it only can be resumed via VGA display when VGA and DP go to sleep mode.

  • Page 41: Touch Screen

    Active: 24.6mA / Idle Mode: 13.4mA 4.2.2 Driver Installation- Windows 7/8.x The GOT817-834 provides a touch screen driver that users can install it under the operating system W indows 7/8.x. To facilitate installation of the touch screen driver, you should read the instructions in this chapter carefully before you attempt installation.
  • Page 42 GOT817-834 User’s Manual Select the “Standard Calibrate” tab. Calibration: To adjust the display with touch panel, click “Calibration” and follow the calibrate point to do calibration; there are five points on screen for calibration. Press OK. Drivers Installation...
  • Page 43 GOT815-834 User’s Manual Embedded O.S. The GOT817-834 provides the W ES 7 and W E8S Embedded. The O.S. is supported devices which are listed below. 4.3.1 WES 7 & WE8S Here are supported onboard devices: Onboard Multi I/O  SATA HDD ...
  • Page 44 GOT817-834 User’s Manual This page is intentionally left blank. Drivers Installation...
