rBOX510-6COM User's Manual
The wireless socket is near heatsink cover side
Step 1 Turn off the system.
Step 2 Loosen all screws of the cover and remove the cover from the system.
Step 3
Take out the thermal pad form the wireless module kit, then stick on the
thermal parts.
Note: Must use the dedicated option wireless module kit for rBOX510-6COM.
22
Hardware Installation
