This chapter contains general information and detailed specifications of the rBOX510-6COM.
The Chapter 1 includes the following sections:


General Description

 System Specification

Dimensions
 I/O Outlets
1.1 General Description
rBOX510-6COM Din-rail fanless embedded system is suitable for communications
control and for protocol converter applications in critical environments. Built for
rugged work environments,
®
consumption Intel
supporting industrial temperature range of -40℃ to +70℃. Its front accessible I/O
cabling is very convenient for wiring and maintenance. rBOX510-6COM offers a
VGA output, making it particularly well-suited for communication control, SCADA
and industrial automation. Its compact size with Din -rail mounting allows for easy
installation into control cabinet. Pre-installed with Linux, Windows
Windows 8 embedded, rBOX510-6COM provides programmers with a friendly
environment for developing application software at a lower cost.
rBOX510-6COM is robust industrial-grade hardware design and adopts the
advanced cooling system , besides, supporting the CompactFlash™ and SATA SSD
(or HDD), which makes it especially suitable for field control & monitoring system
solution for following markets:
Utility Industries (Water; Energy; Chemical Plant; Mining...)
Public Transportation Industries (Traffic/ Highway Control; Train/Bus Control...)
Homeland Security (Weather Monitoring/Alarm System...)
 Features
 Fanless design
 Wide temperature operation of -40℃ - +70℃
 Supports 2 10/100/1000 Base-T Ethernets with Magnetic Isolated Protection
 4 isolated RS-232/422/485 COM Ports and 2 RS-232/422/485 COM Ports
 1 isolated DIO (8-IN/ 8-OUT)
 3 Wireless (3G/GPRS & Wifi)
Support one 2.5" SATA SSD (or HDD), m-SATA and one CompactFlash™


Wide range 12–48V DC-in with terminal block
 Din-rail mounting
 Wall mounting (optional)
 Passed Heavy Industrial CE, FCC Part 18 and UL testing
 Passed ATEX & C1D2 Anti-explosive Certification
Introduction
rBOX510-6COM
™
ATOM E3827 (1.75GHz) or E3845 (1.91GHz) processors
rBOX510-6COM User's Manual
CHAPTER 1
INTRODUCTION
features an extra
®
7 embedded and
low power
1
