Two wireless sockets are near SSD cover side.
Step 1 Turn off the system.
Step 2 Loosen all screws of the cover and remove the cover from the system.
one socket supports mSATA/USB/PCIe interface
Step 3
Plug the wireless module in the wireless socket and use screws to fix tightly.
Step 4
Put the cover back to the system, and fasten screws tight close the
chassis.
Note: The 3G module needs with SIM slot.
Hardware Installation
rBOX510-6COM User's Manual
25
