Pallet Double Stacking

In the event that a forklift is unavailable to safely remove the module, notify the
installation coordinator. Inform them that the library may need to be picked up from
the site by the delivery company, taken off the second pallet, and re-delivered.
Delivery personnel are not authorized to remove the modules from the second pallet
without the proper equipment.

Installation Tools

The tables below lists the installation tools required for the SL3000 library. Obtain the
standard tools locally or from the SL8500 installation kit if available.
Table 8–3
Standard Tools
Torx screwdriver with T8, T10, T15, T25 bits T8: Removal and replacement of the PUK card.
3/8-in. drive ratchet wrench
5/16-in. hex Allen on 3/8-in. drive
9/16-in. socket on 3/8-in.-drive
Adjustable wrench (must accept 7/8-in.
nut)
Phillips and flat blade screwdrivers
Power drill (optional)
Wire side cutters
Multimeter
Flashlight, step stool
Pallet jack
1
Can be obtained from the SL8500 tool kit.
Table 8–4
Special Tools
Copper rail connector
extraction tool
Rail separator/joiner
Serial cable for laptop
Crossover cable for laptop
Drive tray power-on tool
Possible Physical Injury. Only use a forklift operated
WARNING:
by a qualified operator to remove a stacked second pallet. Do not
attempt to tilt or slide the pallet off by hand.

Standard Installation Tools

1
1
1

Special Installation Tools

Part Number Use
313921001
4199410xx
24100134
24100163
314831204
Use
T10: PUO, PUW, PUN, PUF, PUZ cards. Track stops.
T15: Operator panel, window, blank plate, arrays
T25: Shipping brace, rails, and CAP screws.
Module height adjustment, joining modules
Module height adjustment, joining modules
Module removal from pallet
Lock weight distribution pads
General assembly
General assembly. Adjust the torque settings to 2.8 Nm (25
in.-lb) for T-25 screws and 0.6 Nm (5 in.-lb) for T-10 screws.
Cutting shipping straps
Electrical testing
General assembly
Moving equipment
Track terminator removal (obtain from Base installation kit)
Release or join extrusions (obtain from Base installation kit)
CLI access to library (obtain from iProcurement/Zones)
Ethernet access to library (obtain from iProcurement/Zones)
See "Drive Tray Power-on Tool"
from iProcurement/Zones)
Installation Tools
on page 8-4 below (obtain
Installation Planning 8-3
