Summary of Contents for TechnoKom AutoGRAPH-ST
-
Page 2: Table Of Contents
AutoGRAPH-ST – Remote Control Command Table of content Introduction ......................... 5 SMS and server commands ....................6 VERSION ..........................9 NUMBER ........................... 10 GSMPIN ..........................11 GSMAPN ........................... 12 GSMAPNUSER ......................... 13 GSMAPNPASS ......................... 14 MAPFORMAT ........................15 BALANCENUM ......................... 16 BALANCELEVEL ...................... - Page 3 SLP ........................... 52 SRH ........................... 53 CAR ........................... 54 TKR ........................... 55 CRG ..........................56 USR ........................... 57 BAL ........................... 58 TLх ............................ 59 INF ............................ 60 SMS ..........................61 DTS ........................... 62 PSW ..........................63 AutoGRAPH-ST messages ..................... 64...
-
Page 4: Introduction
SMS or data server. All SMS commands should be sent to a number of a SIM card installed into the AutoGRAPH-ST. Reply to the command will be send to a telephone number which sent this command to the device. -
Page 5: Sms And Server Commands
AutoGRAPH- ST – Remote Control Command SMS and server commands of AutoGRAPH-ST remote control... - Page 6 AutoGRAPH-ST – Remote Control Command Control commands are intended for remote configuration of AutoGRAPH-ST devices via SMS or data server without connecting to a PC. SMS command format: 1. Setting: password[space]COMMAND=param; 2. Request: password[space]COMMAND=?; password – four-figure secure password of the AutoGRAPH-ST;...
- Page 7 3 specified for sending SMS with coordinates: 1234 SMSNUMBER3=; AutoGRAPH-ST is designed this way that the settings are valid either till the device restart or till an integrated GSM modem restart. In order not to reset settings after the restart, it is necessary to save them with the command “SAVECONFIG”...
-
Page 8: Version
AutoGRAPH-ST – Remote Control Command VERSION Command VERSION Name Firmware version request Supported with firmware AGST-0.75 and higher Description Command is intended for requiring a firmware version of the AutoGRAPH-ST. Command format: password VERSION=?; Sample command: 5672 VERSION=?; Sample reply: #VERSION=AGST-1.0;... -
Page 9: Number
AutoGRAPH- ST – Remote Control Command NUMBER Command NUMBER Name Serial number request Supported with firmware AGST-0.75 and higher. Description Command is intended for requiring of the device serial number. The serial number is assigned by the manufacture and won‟t be changed. Command format: password NUMBER=?;... -
Page 10: Gsmpin
AutoGRAPH-ST – Remote Control Command GSMPIN Command GSMPIN Name PIN setup. Supported with firmware AGST-0.75 and higher. Description Command is intended for setting a PIN of the SIM card inserted into the device. Command format: password GSMPIN=pin; parameters of the command: ... -
Page 11: Gsmapn
AutoGRAPH- ST – Remote Control Command GSMAPN Command GSMAPN Name APN setup Supported with firmware AGST-0.75 and higher Description Command is intended for specifying a name of GPRS access point. Command format: password GSMAPN=apn; parameters of the command: apn – a name of GPRS access point. To enquire APN settings contact with your mobile operator or get it from the operator‟s official web site. -
Page 12: Gsmapnuser
AutoGRAPH-ST – Remote Control Command GSMAPNUSER Command GSMAPNUSER Name APN user setup Supported with firmware AGST-0.75 and higher Description Command is intended for specifying a user name of APN. Command format: password GSMAPNUSER=user; parameters of the command: user – a user name of the APN. To enquire APN settings contact with your mobile operator or get it from the operator‟s official web site. -
Page 13: Gsmapnpass
AutoGRAPH- ST – Remote Control Command GSMAPNPASS Command GSMAPNPASS Name APN password setup Supported with firmware AGST-0.75 and higher Description Command is intended for specifying password of APN. Command format: password GSMAPNPASS=apn_pass; parameters of the command: apn_pass – password of the APN. To enquire APN settings contact with your mobile operator or get it from the operator‟s official web site. -
Page 14: Mapformat
2 – Coordinates – coordinates will be sent in standard format – longitude and latitude values. Sample command: 5672 MAPFORMAT=1; Sample reply: #MAPFORMAT=1; The device is specified to send coordinates as a link to Google Maps. Note: MAPFORMAT command is supported by AutoGRAPH-ST devices with a firmware of version AGST-1.11 and higher. -
Page 15: Balancenum
AutoGRAPH- ST – Remote Control Command BALANCENUM Command BALANCENUM Name SIM Balance Checking Settings Supported with firmware AGST-0.81 and higher Description Command is intended for specifying a code for checking balance of the device SIM card and setting parameters of notifying about balance state. Command format: password BALANCENUM=number,email,sms;... -
Page 16: Balancelevel
AutoGRAPH-ST – Remote Control Command BALANCELEVEL Command BALANCELEVEL Name Low SIM balance notification Supported with firmware AGST-1.15 and higher Description Command is intended to set a minimal balance level to initiate sending of notification to user. Command format: password BALANCELEVEL=level;... -
Page 17: Gsmserver
AutoGRAPH- ST – Remote Control Command GSMSERVER Command GSMSERVER Name Data server address Supported with firmware AGST-0.75 and higher Description Command is intended to set an address of data server which the device transfers data to. Command format: password GSMSERVER=server; parameters of the commands: ... -
Page 18: Gsmport
AutoGRAPH-ST – Remote Control Command GSMPORT Command GSMPORT Name Data server port Supported with firmware AGST-0.75 and higher Description Command is intended to set a port number of data server which the device sends data to. Be sure that the specified port is enabled in the server firewall settings. -
Page 19: Gsmpass
AutoGRAPH- ST – Remote Control Command GSMPASS Command GSMPASS Name Data server password Supported with firmware AGST-0.75 and higher Description Command is intended to setup a password to access to the data stored on the server. Password must be exactly 8 characters long and can consist of uppercase and lowercase letters and figures from 0 to 9. -
Page 20: Serveren
AutoGRAPH-ST – Remote Control Command SERVEREN Command SERVEREN Name Data transmission to server Supported with firmware AGST-0.75 and higher Description Command allows enabling disabling data transmission to the server. If the option is enabled, the device will switch to the tracking mode and transfer data to the specified server with preset period or at scheduled time. -
Page 21: Serverperiod
#SERVERPERIOD=15,30,1; The device is set up to the data every day at 15:30. Note: Parameter “type” is available for AutoGRAPH-ST devices with firmware of version AGST-0.81 and higher. For the previous versions of firmware, use “SERVERPERIOD=hours,minutes;”. following format of the command:... -
Page 22: Smtpserver
AutoGRAPH-ST – Remote Control Command SMTPSERVER Command SMTPSERVER Name SMTP server address Supported with firmware AGST-0.75 and higher Description Command is intended to set SMTP server address which will be used for sending Email with current coordinates. Command format: password SMTPSERVER=server;... -
Page 23: Smtpport
AutoGRAPH- ST – Remote Control Command SMTPPORT Command SMTPPORT Name SMTP server port Supported with firmware AGST-0.75 and higher Description Command is intended to set SMTP server port for sending Email with current coordinates. Command format: password SMTPPORT=port; parameters of the command: ... -
Page 24: Smtplogin
AutoGRAPH-ST – Remote Control Command SMTPLOGIN Command SMTPLOGIN Name SMTP server login Supported with firmware AGST-0.75 and higher Description Command is intended to set up a login used for sending Email via specified SMTP server. To enquire your login, contact Administrator of the SMTP server. -
Page 25: Smtppass
AutoGRAPH- ST – Remote Control Command SMTPPASS Command SMTPPASS Name Password for accessing the SMTP server Supported with firmware AGST-0.75 and higher Description Command is intended to set up a password used to access to SMTP server. To set a login, use “SMTPLOGIN”... -
Page 26: Smtpfrom
AutoGRAPH-ST – Remote Control Command SMTPFROM Command SMTPFROM Name Mail account of the device Supported with firmware AGST-0.75 and higher Description Command is intended to set mail address which the device uses to send Email. Command format: password SMTPFROM=username; parameters of the command: ... -
Page 27: Smtptox
AutoGRAPH- ST – Remote Control Command SMTPTOx Command SMTPTOx Name Mail addresses for sending Email Supported with firmware AGST-0.75 and higher Description Command is intended to set mail addresses which the device will send Email to. Command format: password SMTPTOx=address; parameters of the command: ... -
Page 28: Smtpen
AutoGRAPH-ST – Remote Control Command SMTPEN Command SMTPEN Name Sending Email Supported with firmware AGST-0.75 and higher Description Command allows enabling or disabling Email sending option. Формат команды: password SMTPEN=flag; parameters of the command: flag – specify following value: 0 –... -
Page 29: Smtpperiod
The device is set up to send Email with a period of 48 hours 30 min. Note: Parameter “type” is available for AutoGRAPH-ST devices with firmware of version AGST-0.81 and higher. For the previous versions of firmware, use the following format of the command: “SMTPPERIOD=hours,minutes;”. -
Page 30: Smsnumberx
AutoGRAPH-ST – Remote Control Command SMSNUMBERx Command SMSNUMBERx Name Telephone numbers for sending SMS Supported with firmware AGST-0.75 and higher Description Command is intended to set telephone numbers which the device will send SMS to. Command format: password SMSNUMBERx=tel_number; parameters of the command: ... -
Page 31: Smsgate
AutoGRAPH- ST – Remote Control Command SMSGATE Command SMSGATE Name SMS gateway number Supported with firmware AGST-1.11 and higher Description Command is intended to set a number of SMS gateway which will be used for sending current position data to data server by means of SMS. -
Page 32: Smsen
SMS sending with current position data is enabled in the device. Note: Sending data to the server via SMS gate is available in AutoGRAPH-ST devices with firmware of version AGST-1.11 or higher. For previous versions of the firmware use the following format of the command “SMSEN=sms;”. -
Page 33: Smsperiod
AutoGRAPH- ST – Remote Control Command SMSPERIOD Command SMSPERIOD Name SMS sending period Supported with firmware AGST-0.75 and higher Description Command is intended to set up a period or time of sending SMS with current position data to preset telephone numbers. This command is used to specify both the period of SMS sending and the exact time of sending SMS. -
Page 34: Devname
AutoGRAPH-ST – Remote Control Command DEVNAME Command DEVNAME Name Device alias setting Supported with firmware AGST-0.75 and higher Description Command is intended to set device name (alias) which provides identification of SMS and Email from the device. Command format: password DEVNAME=alias;... -
Page 35: Delayoff
AutoGRAPH- ST – Remote Control Command DELAYOFF Command DELAYOFF Name Sleep mode delay Supported with firmware AGST-0.75 and higher Description Command is intended to set up a delay of switching to sleep mode. If the delay is enabled, the device will stay in tracking mode during the delay after sending SMS with position data. -
Page 36: Indoff
AutoGRAPH-ST – Remote Control Command INDOFF Command INDOFF Name Indication turning off Supported with firmware AGST-0.75 and higher Description Command is intended for turning off LED indication of the device. It would be necessary to save battery life in case of critical low voltage level the battery. -
Page 37: Alarm
AutoGRAPH- ST – Remote Control Command ALARM Command ALARM Name Alarm mode setting Supported with firmware AGST-0.75 and higher Description Command is intended to turn on an Alarm mode. This mode enables data sending via GPRS (to data server), SMS and Email every 10 minutes. The device will send data via all channels even if some data transmission channels are disabled. -
Page 38: Acclen
Sample reply: #ACCLEN=1; The device accelerometer is enabled. The AutoGRAPH-ST device is equipped with an internal accelerometer optionally. So the configuration commands intended for the device accelerometer are applicable only for AutoGRAPH-ST devices equipped with accelerometer. To check if the device is equipped with internal accelerometer, read its configuration using the AGSTConf application or send SMS request «ACCLEN=?;». -
Page 39: Acclsetuplev
AutoGRAPH- ST – Remote Control Command ACCLSETUPLEV Command ACCLSETUPLEV Name Accelerometer settings Supported with firmware AGST-0.75 and higher Description Command intended configure device accelerometer. Command format: password ACCLEN= scale,threshold; parameters of the command: scale – accelerometer range: 0 – +/-2g; 1 –... -
Page 40: Acclsetupsend
AutoGRAPH-ST – Remote Control Command ACCLSETUPSEND Command ACCLSETUPSEND Name Accelerometer notifications settings Supported with firmware AGST-0.75 and higher Description Command is intended to set up notifications which the device sends when internal accelerometer triggers. Command format: password ACCLSETUPSEND=sms, data,email; parameters of the command: ... -
Page 41: Fastmovedetect
AutoGRAPH- ST – Remote Control Command FASTMOVEDETECT Command FASTMOVEDETECT Name Quick accelerometer notification Supported with firmware AGST-1.32 and higher Description Command is intended to enable quick notification when accelerometer detects motion start or other affects. When this option is enabled, the device will send a notification without position data immediately after the motion detection. -
Page 42: Saveconfig
AutoGRAPH-ST – Remote Control Command SAVECONFIG Command SAVECONFIG Name Configuration saving Supported with firmware AGST-0.75 and higher Description Command is intended for saving all new settings which will be sent to the device after the last restart. If the settings haven‟t been saved with this command they will be valid till the device restart (or restart of GSM modem). -
Page 43: Securesetup
AutoGRAPH- ST – Remote Control Command SECURESETUP Command SECURESETUP Name Device password activation Supported with firmware AGST-0.75 and higher Description Command is intended to disable the device settings protection. If the protection is enabled it will be unavailable to change the settings by means of the AGSTConf Software without entering the security password. - Page 44 AutoGRAPH-ST – Remote Control Command Sample command: 5672 SECURESETUP=1,5672; Sample rely: #SECURESETUP=1,1; The protection password is enabled in the device. So the device configuration using AGSTConf Software is available only after entering the password.
-
Page 45: Gpsen
AutoGRAPH- ST – Remote Control Command GPSEN Command GPSEN Name Data recording option Supported with firmware AGST-1.11 and higher Description Command enables position data recording, which means that the device will switch to the tracking mode, acquire position and record that data in internal memory. In this case the device doesn‟t send the obtained data to customer. -
Page 46: Gpsperiod
AutoGRAPH-ST – Remote Control Command GPSPERIOD Command GPSPERIOD Name Data recording period Supported with firmware AGST-1.11 and higher Description Command is intended for specifying data recording period. Command format: password GPSPERIOD=hour,min; parameters of the command: hour,min– period of data recording. The period must be specified in the following format hour,minute. -
Page 47: Setcp
Name Geofencing Supported with firmware AGST-1.16 and higher Description Command provides to specify geofence settings and enable it control. AutoGRAPH-ST supports only circle geofences. Command formats: password SETCP=status,lat,lon,radius,flags; parameters of the command: status – specify the following value: 0 – to disable geofence control;... - Page 48 AutoGRAPH-ST – Remote Control Command Sample command: 5672 SETCP=1,55.173328,61.383743,300,6; Sample reply: #SETCP=1,55.173328,61.383743,300,6; Control of the geofence with a center in 55.173328°, 61.383743° point is enabled in the device. When entering to this geofence, the device will send SMS with the current position data.
-
Page 49: Short Sms Commands
AutoGRAPH- ST – Remote Control Command Short SMS Commands... - Page 50 password – 4-digit settings protection password of the device. [space] – space symbol. SHORT_COMMAND – short command. param – parameters of the short command. Note: Short SMS commands are supported with the AutoGRAPH-ST devices with firmware of version AGST-1.12 or higher.
-
Page 51: Slp
AutoGRAPH- ST – Remote Control Command Command Name Sleep profile activation Supported with firmware AGST-1.12 and higher Description Command is intended for enabling Sleep profile. If the profile is enabled the device acquires the position data with specified period and records it into the internal memory. -
Page 52: Srh
AutoGRAPH-ST – Remote Control Command Command Name Search profile activation Supported with firmware AGST-1.12 and higher Description Command is intended for enabling Search profile. If the profile is enabled, the device acquires the position data with specified period and sends it to data server and telephone numbers via SMS. -
Page 53: Car
AutoGRAPH- ST – Remote Control Command Command Name Car profile activation Supported with firmware AGST-1.12 and higher Description Command is intended for enabling Car profile. If the profile is enabled, the device acquires position data every day at scheduled time and sends SMS with the current position data to specified telephone numbers. -
Page 54: Tkr
AutoGRAPH-ST – Remote Control Command Command Name Tracker profile activation Supported with firmware AGST-1.12 and higher Description Command is intended for enabling Tracker profile. If the profile is enabled, the device acquires position data with specified period and records the data into internal memory. -
Page 55: Crg
AutoGRAPH- ST – Remote Control Command Command Name Cargo profile activation Supported with firmware AGST-1.12 and higher Description Command is intended for enabling Cargo profile. If the profile is enabled, the device acquires the position data with specified period and sends it to the data server and to telephone numbers via SMS. -
Page 56: Usr
AutoGRAPH-ST – Remote Control Command Command Name User profile activation Supported with firmware AGST-1.12 and higher Description Command is intended for enabling User profile. A customer can specify User profile by means of AGSTConf software in user-defined way and activate the profile with “USR”... -
Page 57: Bal
AutoGRAPH- ST – Remote Control Command Command Name Balance checking Supported with firmware AGST-1.12 and higher Description Command is intended for checking a current balance of the SIM card installed in the device. Command format: password BAL code parameters of the command: ... -
Page 58: Tlх
AutoGRAPH-ST – Remote Control Command TLх Command TLх Name Telephone number for SMS Supported with firmware AGST-1.12 and higher Description Command is intended for setting telephone number which the device will send SMS to. Command format: password TLx tel_number parameters of the command: ... -
Page 59: Inf
AutoGRAPH- ST – Remote Control Command Command Name Device setting request Supported with firmware AGST-1.12 and higher Description Command provides request of device main setting. Command format : password INF Reply format: #INF PRF=profile SMS=H:M,type SMTP=H:M,type SRV=H:M,type GPS=H:M,PR parameters of the reply: ... -
Page 60: Sms
AutoGRAPH-ST – Remote Control Command Command Name SMS sending settings Supported with firmware AGST-1.12 and higher Description Command provides to set up SMS sending parameters. Command format: password SMS SRV TEL parameters of the command: SRV – enables SMS sending via SMS gateway. -
Page 61: Dts
AutoGRAPH- ST – Remote Control Command Command Name Date and Time settings Supported with firmware AGST-1.12 and higher Description Command is intended to set up the device date and time. Command format: password DTS hour:min day.month.year time_zone parameters of the command (all parameters of the command must be specified in next order): ... -
Page 62: Psw
AutoGRAPH-ST – Remote Control Command Command Name Protection password changing Supported with firmware AGST-1.12 and higher Description Command is intended to change the device protection password. Command format: password PSW new_password parameters of the command: new_password – a new security password. The password must be 4 characters long and consist of only figures from 0 to 9. -
Page 63: Autograph-St Messages
AutoGRAPH- ST – Remote Control Command AutoGRAPH-ST messages... - Page 64 AutoGRAPH-ST – Remote Control Command If the device is set up to send an SMS with coordinates, it will send an SMS with current position to all preset telephone numbers. The SMS with coordinates has the following syntax (there are two cases): ...
- Page 65 SIM balance - current balance of device‟s SIM card. To get the balance in the SMS, the proper option must be enabled and the code for balance check must be preset in the device. Sample: AutoGRAPH-ST USR 11:11:2013 10:11 (6) http://maps.google.com/maps?near=54.891343+61.393755&t=h PRC: 1000m 6.7V,25C,-65dBm,s0,#6...
- Page 66 AutoGRAPH-ST – Remote Control Command parameters of base station to which it is connected, along with parameters of the six nearest base stations, to the customer. Different notifications may also be sent by SMS with the coordinates: LOW BATTERY – a notification about low voltage level of battery.
- Page 67 CONTROL SMS AND SERVER COMMANDS v.1.32 TechnoKom Ltd. www.tk-nav.com info@tk-nav.com Copyright © Chelyabinsk, 2015 All Rights Reserved.
