2.1.3. IP55 Enclosed Units
Model Code
ODV-3-420300-3F1N-TN
ODV-3-420460-3F1N-TN
ODV-3-520610-3F1N-TN
ODV-3-520720-3F1N-TN
ODV-3-620900-3F1N-TN
ODV-3-621 100-3F1N-TN
ODV-3-621500-3F1N-TN
ODV-3-621800-3F1N-TN
ODV-3-722020-3F1N-TN
ODV-3-722480-3F1N-TN
Model Code
ODV-3-440300-3F1N-TN
ODV-3-440390-3F1N-TN
ODV-3-440460-3F1N-TN
ODV-3-540610-3F1N-TN
ODV-3-540720-3F1N-TN
ODV-3-540900-3F1N-TN
ODV-3-641 100-3F1N-TN
ODV-3-641500-3F1N-TN
ODV-3-641800-3F1N-TN
ODV-3-742020-3F1N-TN
ODV-3-742400-3F1N-TN
ODV-3-743020-3F1N-TN
Model Code
ODV-3-751850-301N-TN
ODV-3-752050-301N-TN
ODV-3-752550-301N-TN
ODV-3-752750-301N-TN
Model Code
ODV-3-460220-301N-TN
ODV-3-460280-301N-TN
ODV-3-460340-301N-TN
ODV-3-460430-301N-TN
ODV-3-560540-301N-TN
ODV-3-560650-301N-TN
ODV-3-660780-301N-TN
ODV-3-661050-301N-TN
ODV-3-661300-301N-TN
ODV-3-661500-301N-TN
www.invertekdrives.com
200 – 240 Volt, 3 Phase Input
Frame kW
4 7.5
4 1 1
5 15
5 18.5
5 22
6 30
6 37
6 45
7 55
7 75
380 – 480 Volt, 3 Phase Input
Frame kW
4 15
4 18.5
4 22
5 30
5 37
5 45
6 55
6 75
6 90
7 1 10
7 132
7 160
480 – 525 Volt, 3 Phase Input
Frame kW
7 132
7 150
7 185
7 200
500 – 600 Volt, 3 Phase Input
Frame kW
4 15
4 18.5
4 22
4 30
5 37
5 45
6 55
6 75
6 90
6 1 10
HP Amps Low Harmonic
10 30
15 46
20 61
25 72
30 90
40 1 10
50 150
60 180
75 202
100 248
HP Amps Low Harmonic
20 30
25 39
30 46
40 61
50 72
60 90
75 1 10
100 150
150 180
175 202
200 240
250 302
HP Amps Low Harmonic
175 185
200 205
250 255
270 275
HP Amps Low Harmonic
20 22
25 28
30 34
40 43
50 54
60 65
75 78
100 105
125 130
150 150
Version 3.05 | Optidrive Eco User Guide | 7
