9.5. Advanced Parameters

For Advanced Parameters, basic information only is provided in this guide. The parameter functions are described more fully in
Optitools Studio PC software.
9.5.1. Parameter Group 6 – Advanced Configuration
Par. Function
P6-01
Firmware Upgrade Enable
P6-02
Thermal Overload Management
P6-03
Auto Reset Time Delay
P6-04
Relay Output Hysteresis
P6-08
Max Speed Reference Frequency
P6-10
Function Block Program Enable
P6-11
Speed Hold Time on Enable
P6-12
Speed Hold / DC Injection Time on Disable
P6-18
DC Injection Current
P6-22
Reset Fan Run Time
P6-23
Reset Energy Meters
P6-24
Maintenance Time Interval
P6-25
Reset Maintenance Indicator
P6-26
Analog Output 1 Scaling
P6-27
Analog Output 1 Offset
P6-28
P0-80 Display Index
P6-29
User Default Parameters
P6-30
Level 3 (Advanced) Access Code
www.invertekdrives.com
Setting Range
0 Disabled
1 Update I/O & P/S
2 Update I/O
3 Update P/S
4 – 32kHz (Model Dependent)
1 – 60 Seconds
0.0 – 25.0%
0 – 20kHz
0 Disabled
1 Enabled
0 – 250s
0 – 250s
0.0 – 100.0%
0 No Reset
1 Reset
0 No Reset
1 Reset
0 – 60000 Hours
0 No Reset
1 Reset
0.0 – 500.0%
-500.0 – 500.0%
0 - 255
0 No Function
1 Save user parameters
2 Clear user parameters
0 – 9999
Version 3.05 | Optidrive Eco User Guide | 49
Default Notes
0 This parameter should not be
adjusted by the user.
4 kHz Minimum Effective Switching
Frequency.
20s
0.3%
0 kHz
0
0s
0s
0.0% This function is active only
for Induction Motors (IM)
and Synchronous Reluctance
Motor (SyncRM).
0
0
0 Hours
0
100.0%
0.0%
0
0
201
9
