  • Page 1 AC Variable Speed Drive 0.75 - 250kW / 1 - 350HP 200-600V Single and 3 Phase Input Introduction General Information and Ratings Mechanical Installation Electrical Installation LED Keypad and Display Operation Commissioning Parameters Control Terminal Functions Extended Parameters Serial Communications Technical Data Troubleshooting...

  • Page 2: Table Of Contents

    1. Introduction ......6. Commissioning ........1.
  • Page 3 P0-28. User Guide Revision 3.07 Invertek Drives Ltd adopts a policy of continuous improvement and whilst every effort has been made to provide accurate and up to date information, the information contained in this User Guide should be used for guidance purposes only and does not form the part of any contract.

  • Page 4: Introduction

    1. Introduction 1.1. Important Safety Information Please read the IMPORTANT SAFETY INFORMATION below, and all Warning and Caution information elsewhere. Danger: Indicates a risk of electric shock, Danger: Indicates a potentially hazardous situation which, if not avoided, could result in damage to other than electrical, which if not avoided, could the equipment and possible injury or death.

  • Page 5: General Information And Ratings

    2. General Information and Ratings 2.1. Drive Model Numbers 2.1.1. IP20 Units 200 – 240 Volt, 1 Phase Input Model Code Frame Amps Low Harmonic ODV-3-220043-1F12-TN 0.75 ODV-3-220070-1F12-TN ODV-3-220105-1F12-TN 10.5 200 – 240 Volt, 3 Phase Input Model Code Frame Amps Low Harmonic ODV-3-220043-3F12-TN...
  • Page 6 500 – 600 Volt, 3 Phase Input Model Code Frame Amps Low Harmonic ODV-3-260021-3012-TN 0.75 2. 1 ODV-3-260031-3012-TN 3. 1 ODV-3-260041-3012-TN 4. 1 ODV-3-260065-3012-TN ODV-3-260090-3012-TN ODV-3-360120-3012-TN ODV-3-360170-3012-TN ODV-3-360220-3012-TN ODV-3-460280-3012-MN 18.5 ODV-3-460340-3012-MN ODV-3-460430-3012-MN ODV-3-560540-3012-MN ODV-3-560650-3012-MN 2.1.2. IP66 Enclosed Units 200 – 240 Volt, 1 Phase Input Non-Switched With Disconnect Frame...
  • Page 7 2.1.3. IP55 Enclosed Units 200 – 240 Volt, 3 Phase Input Model Code Frame Amps Low Harmonic ODV-3-420300-3F1N-TN ODV-3-420460-3F1N-TN ODV-3-520610-3F1N-TN ODV-3-520720-3F1N-TN 18.5 ODV-3-620900-3F1N-TN ODV-3-621 100-3F1N-TN 1 10 ODV-3-621500-3F1N-TN ODV-3-621800-3F1N-TN ODV-3-722020-3F1N-TN ODV-3-722480-3F1N-TN 380 – 480 Volt, 3 Phase Input Model Code Frame Amps Low Harmonic...

  • Page 8: Identifying The Drive By Model Number

    2.1.4. Low Harmonic Variants The majority of the Optidrive Eco product range is based on a low harmonic solution using film capacitor technology to achieve compliance with EN 61000-3-12 without the need for any additional equipment. This standard specifies limits for harmonic currents for equipment connected to public low-voltage systems with input current >...

  • Page 9: Mechanical Installation

    3. Mechanical Installation 3.1. General  T he Optidrive should be mounted in a vertical position only, on a flat, flame resistant, vibration free mounting using the integral mounting holes.  D o not mount flammable material close to the Optidrive.  E nsure that the minimum cooling air gaps, as detailed in sections 3.6.

  • Page 10: Mechanical Dimensions And Weight

    3.5. Mechanical Dimensions and Weight 3.5.1. IP20 Units Weight Drive Size 8.70 1 10 4.33 7.28 8.23 2.48 10.28 5. 1 6 8.07 9.72 3. 1 5 16.46 6.77 9.45 15.75 4.92 20.3 19. 1 3 9. 1 7 10.24 18.
  • Page 11 3.5.2. IP55 Units Weight Drive Size 17.72 6.73 9.92 16.85 1 10 4.33 1 1.5 25.4 21.26 9.25 10.63 20.28 6.89 50.7 34.06 12.99 12.99 32.68 7.87 121.2 1280 50.39 12.99 14. 1 7 1245 49.02 7.87 196.2 Mounting Bolts Tightening Torques Frame Size Metric...
  • Page 12 3.5.3. IP66 Units Weight Drive Size 10. 1 2 7.40 9.41 7.87 7.01 10.6 12.20 21 1 8.29 10.47 9.90 7.87 16.8 Mounting Bolts Tightening Torques Frame Size Metric Frame Size Required Torque Control Terminals 2 & 3 0.5 Nm 4.5 lb-in Power Terminals 2 &...

  • Page 13: Guidelines For Enclosure Mounting (Ip20 Units)

     High moisture, salt or chemical content environments should use a suitably sealed (non-vented) enclosure. The enclosure design and layout should ensure that the adequate ventilation paths and clearances are left to allow air to circulate through the drive heatsink. Invertek Drives recommend the following minimum sizes for drives mounted in non-ventilated metallic enclosures: Recommended Above &...

  • Page 14: Mounting The Drive - Ip20 Units

    3.7. Mounting the Drive – IP20 Units  IP20 Units are intended for installation within a control cabinet.  When mounting with screws: o Using the drive as a template, or the dimensions shown above, mark the locations for drilling o Ensure that when mounting locations are drilled, the dust from drilling does not enter the drive o Mount the drive to the cabinet backplate using suitable mounting screws o Position the drive, and tighten the mounting screws securely.

  • Page 15: Guidelines For Mounting (Ip66 Units)

    X –Above & Below Y –Either Side Drive Size 4 (IP55) 0.394 5 (IP55) 0.394 6 (IP55) 0.394 7 (IP55) 0.394 NOTE Typical drive heat losses are approximately 2% of the operating load power. The above dimensions are for guidance only, the operating ambient temperature of the drive MUST be maintained within the specified limits or allowed derating at all times.

  • Page 16: Removing The Terminal Cover

    3.10. Removing the Terminal Cover 3.10.1. Frame Sizes 2 & 3 Terminal Cover Release Screws Using a suitable flat blade screwdriver, rotate retaining screws indicated by arrows until the screw slot is vertical. 3.10.2. Frame Size 4 3.10.3. Frame Size 5 3.10.4.

  • Page 17: Ip66 (Nema 4X) Lock Off

    3.12. IP66 (NEMA 4X) Lock Off Mains switch-disconnector Lock Off On the switched models the mains switch-disconnector can be locked in the ‘Off’ position using a 20mm standard shackle padlock (not supplied). IP66 / NEMA 4X Unit Lock Off www.invertekdrives.com Version 3.07 | Optidrive Eco User Guide | 17...

  • Page 18: Electrical Installation

    NOTE Enclosed drives are not suitable for rigid conduit system connection. This manual is intended as a guide for proper installation. Invertek Drives Ltd cannot assume responsibility for the compliance or the non-compliance to any code, national, local or otherwise, for the proper installation of this drive or associated equipment.

  • Page 19: Protective Earth (Pe) Connection

    4.2. Protective Earth (PE) Connection 4.2.1. Grounding Guidelines Adequate safety earthing must be provided in accordance with local wiring rules and codes of practice. The ground terminal of each Optidrive should be connected back to the common safety earth bar to maintain touch potentials within safe limits. The ground terminal of each Optidrive should be individually connected DIRECTLY to the site ground bus bar (through the EMC filter if installed).

  • Page 20: Emc Compliant Installation

    4.3. EMC Compliant Installation 4.3.1. Recommended Installation for EMC Compliance Control cables Twisted-Pair shielded cables for analog Mounting plate control and motor with conductive feedback signals. service ≥ 100mm For Best-Practice use 360° bonding EMC cable gland shielded to motor chassis. U V W PE Fuse / Cable shield exposed...
  • Page 21 General Compliance with category C1 conducted emissions only is achieved. Supply Cable A screened (shielded) cable suitable for fixed installation with the relevant mains voltage in use. Braided or twisted type screened cable where the screen covers at least 85% of the cable surface area, designed with low impedance to HF signals. Installation of a standard cable within a suitable steel or copper tube is also acceptable - in this case, ensure that metal tube is adequately grounded.

  • Page 22: Incoming Power Connection

    4.4. Incoming Power Connection  P ower should be connected to the L1 and L2 terminals for single phase drives, L1, L2 and L3 for three phase drives. Phase sequence is not important.  F or compliance with CE and C Tick EMC requirements, a symmetrical shielded cable is recommended.  A fixed installation is required according to IEC61800-5-1.

  • Page 23: Drive And Motor Connection

    4.6. Drive and Motor Connection  T he drive inherently produces fast switching of the output voltage (PWM) to the motor compared to the mains supply, for motors which have been wound for operation with a variable speed drive then there is no preventative measures required, however if the quality of insulation is unknown then the motor manufacturer should be consulted and preventative measures may be required.

  • Page 24: Motor Thermal Overload Protection

    4.8. Motor Thermal Overload Protection 4.8.1. Internal Thermal Overload Protection Optidrive Eco has internal motor overload protection (current limit) set at 1 10% of the motor rated current (P1-08). This level may be adjusted in P4-07. The drive has an in-built motor thermal overload function; this is in the form of an “I.t-trP” trip after delivering >100% of the value set in P1-08 (motor rated current) for a sustained period of time.
  • Page 25 4.9.1. Control Connections 1 (+24V DC/ 100mA) 0-10V (AO 1) 8 10-0V 0/4-20 mA 20-4/0 mA 2 (Dl 1) (0V/ COM) 9 +24 V DC** 0-10V 3 (Dl 2) 10-0V (AO 2) 11 0/4-20 mA 4 (Dl 3) 20-4/0 mA 5 (+10V DC/ 10mA) 0-10 V 10-0 V...

  • Page 26: Control Terminal Connections

    4.10. Control Terminal Connections 4.10.1. +24VDC Input / Output When the mains power is applied to the drive, terminal 1 provides a +24VDC output, maximum load 100mA. This may be used to activate digital inputs or provide power to sensors. When no mains power is applied to the drive, the drive control electronics may be powered from an external +24VDC source.

  • Page 27: Safe Torque Off

    4.10.5. Auxiliary Relay Outputs Two relay outputs are available, which are intended to be used to switch external resistive loads up to 5A at 230 VAC or 30VDC. Relay 1 has both normally open and normally closed contacts available. Relay 2 provides a simple open or closed contact. The relay output function may be configured using parameters P2-15 and P2-18, which are described in section 8.
  • Page 28 4.11.3. “STO“ Operation When the “STO” inputs are energised, the “STO” function is in a standby state, if the drive is then given a “Start signal/command” (as per the start source method selected in P1-13) then the drive will start and operate normally. When the “STO”...
  • Page 29 4.11.7. Recommended “STO” Wiring Using an External 24V DC Power Supply Using the Drives On-board 24V DC Supply Protective Capped Trunking or equivalent to prevent Protective Capped Trunking Protective Capped Trunking STO Cable short circuit to an or equivalent to prevent or equivalent to prevent external Voltage source .
  • Page 30 4.11.10. Enabling the “STO” Function The “STO” function is always enabled in the drive regardless of operating mode or parameter changes made by the user. In order to ensure that the drive does not immediately re-start when the STO is energised, the 'start mode' (P2-36) should be set to 'Edge-r' as opposed to the default value of 'Auto-0'.

  • Page 31: Keypad And Display Operation

    5. Keypad and Display Operation The drive is configured and its operation monitored via the keypad and display. 5.1. OLED Keypad and Display Layout Control Keypad provides access to the drive parameters, and also allows control of the drive when Keypad Mode is selected in P1-12. TFT Display Main Displayed Parameter Drive Address...

  • Page 32: Selecting The Language On The Tft & Oled Display

    5.2. Selecting the Language on the TFT & OLED Display 01 Select Language Select Language STOP Español Español Deutsch Deutsch 15kW 400V 3Ph English English Hold down the Start Use the Up and Down Press the Navigate and Up keys for >1s arrows to select a button to select.

  • Page 33: Changing Parameters

    Switching Frequency Mains Loss Maintenance Reduction Time Elapsed TFT and OLED Display : 01 ECO 01 ECO 23.7Hz 23.7Hz 23.7Hz SF 15.3A 15.3A 6.9kW 15.3A 6.9kW Switching frequency is The incoming mains The user programmable reduced, due to high heatsink power supply has been maintenance reminder time temperature.

  • Page 34: Parameter Factory Reset / User Reset

    5.5. Parameter Factory Reset / User Reset Optidrive ECO provides a feature to allow the user to define their own default parameter set. After commissioning all required parameters, the user can save these as the default parameters by setting P6-29 = 1. If required, the User Default Parameters may be cleared by setting P6-29 = 2.

  • Page 35: Keypad Shortcuts

    5.8. Keypad Shortcuts The following shortcuts can be used to speed up selecting and changing parameters when using the keypad. 5.8.1. Selecting the Parameter Groups When extended or advanced parameter access is enabled (see section 9. Extended Parameters on page 40), additional parameter groups are visible, and may be selected quickly by the following method.

  • Page 36: Commissioning

    6. Commissioning 6.1. General The following guidelines apply to all applications: 6.1.1. Entering the Motor Nameplate Information Optidrive Eco uses the information from the motor nameplate to:  Operate the mot or with the best possible efficiency level.  Protect the motor against possible damage due to operation in overload condition. In order to achieve this, the Optidrive requires that the following information from the motor nameplate is entered into the parameters: P1-07 Motor Rated Voltage.

  • Page 37: Parameters

    7. Parameters 7.1. Parameter Set Overview The Optidrive Eco Extended Parameter set consists of 7 groups as follows:  Group 1 – Basic Parameter Set  Group 2 – Extended Parameter Set  Group 3 – User PID Control Parameter Set  Group 4 –...
  • Page 38 Par. Parameter Name Minimum Maximum Default Units P1-10 Motor Rated Speed 30000 This parameter can optionally be set to the rated (nameplate) Rpm of the motor. When set to the default value of zero, all speed related parameters are displayed in Hz, and the slip compensation for the motor is disabled. Entering the value from the motor nameplate enables the slip compensation function, and the Optidrive display will now show motor speed in estimated Rpm.

  • Page 39: Control Terminal Functions

    8. Control Terminal Functions 8.1. Digital Input Configuration Parameter P1-13 Local Analog Digital Analog P1-13 (Hand) Digital Input 1 Digital Input 2 Input 1 Input 3 Input 2 Notes Control (Terminal 2) (Terminal 3) (Terminal *(2) (Terminal 4) (Terminal 10) Function All functions User defined in Menu 9 or configured through PLC function in OptiTools studio software suite.

  • Page 40: Extended Parameters

    9. Extended Parameters 9.1. Parameter Group 2 – Extended parameters Par. Parameter Name Minimum Maximum Default Units P2-01 Preset Frequency / Speed 1 -P1-01 P1-01 50.0 (60.0) Hz / Rpm P2-02 Preset Frequency / Speed 2 -P1-01 P1-01 40.0 Hz / Rpm P2-03 Preset Frequency / Speed 3 -P1-01...
  • Page 41 Par. Parameter Name Minimum Maximum Default Units P2-12 Analog Output 1 Format  -  - = 0 to10V  - = 10 to 0V  - = 0 to 20mA  - = 20 to 0mA  - = 4 to 20mA ...
  • Page 42 Par. Parameter Name Minimum Maximum Default Units P2-15 Relay 1 Function Selects the function assigned to Relay Output 1. The relay has normally open and normally closed contacts. Logic 1 indicates the relay is active, and therefore the normally open contact is closed (terminals 14 and 15 will be linked together) and the normally closed contact is opened (terminals 14 and 16 will no longer be connected together).
  • Page 43 Par. Parameter Name Minimum Maximum Default Units P2-21 Display Scaling Factor -30.000 30.000 0.000 Determines the factor for scaling display. The variable selected in P2-22 is scaled by the factor set in P2-21. P2-22 Display Scaling Source Source value used when custom units are to be shown on the drive display. 0 : Motor Speed 1 : Motor Current 2 : Analog Input 2...
  • Page 44 Par. Parameter Name Minimum Maximum Default Units P2-31 Analog Input 1 Scaling 2000.0 100.0 P2-31 is used to scale the analog input prior to being applied as a reference to the drive. For example, if P2-30 is set for 0 – 10V, and the scaling factor is set to 200.0%, a 5 volt input will result in the drive running at maximum speed (P1-01).

  • Page 45: Parameter Group 3 - Pid Control

    Par. Parameter Name Minimum Maximum Default Units P2-39 Parameter Lock 0 : Unlocked. All parameters can be accessed and changed 1 : Locked. Parameter values can be displayed, but cannot be changed. Also disables Hand and Auto button on keypad. P2-40 Extended Menu Access Code 9999...

  • Page 46: Parameter Group 4 - High Performance Motor Control

    Par. Parameter Name Minimum Maximum Default Units P3-11 PID Error to Enable Ramp 25.0 Defines a threshold PID error level, whereby if the difference between the set-point and feedback value is less than the set threshold, the internal ramp times of the drive are disabled to allow the drive to react quickly to small errors. Where a greater PID error exists, the ramp times are enabled to limit the rate of change of motor speed.

  • Page 47: Parameter Group 5 - Communication Parameters

    Par. Parameter Name Minimum Maximum Default Units P4-03 Vector Speed Controller Proportional Gain 400.0 50.0 Sets the proportional gain value for the speed controller. Higher values provide better output frequency regulation and response. Too high a value can cause instability or even over current trips. For applications requiring best possible performance, the value should be adjusted to suit the connected load by gradually increasing the value and monitoring the actual output speed of the load until the required dynamic behaviour is achieved with little or no overshoot where the output speed exceeds the setpoint.
  • Page 48 Par. Name Minimum Maximum Default Units P5-07 Fieldbus Ramp Control Selects whether the acceleration and deceleration ramps are control directly via the Fieldbus, or by internal drive parameters P1-03 and P1-04. 0 : Disabled. Ramps are control from internal drive parameters. 1 : Enabled.

  • Page 49: Advanced Parameters

    9.5. Advanced Parameters For Advanced Parameters, basic information only is provided in this guide. The parameter functions are described more fully in Optitools Studio PC software. 9.5.1. Parameter Group 6 – Advanced Configuration Par. Function Setting Range Default Notes P6-01 Disabled Firmware Upgrade Enable This parameter should not be...

  • Page 50: Parameter Group 8 - Application Function Specific Parameters

    9.5.2. Parameter Group 7 – Motor Control Par. Function Setting Range Default Notes 0.000 – 65.535 P7-01 Motor Stator Resistance Drive Motor data, measured or calculated curing the autotune. Dependent 0.0000 – 1.0000 P7-03 Motor Stator Inductance (d) P7-04 is not used for PM & BLDC Motors. Drive Dependent P7-04 P7-06 is used only for PM motors.
  • Page 51 Par. Name Minimum Maximum Default Units P8-06 Load Monitor Enable This parameter enables the Total Motor Current Profile Monitoring Function, which can be used to detect belt failure in belt driven fan applications, or Dry Pump, Pump Blockage or broken impeller in Pump applications. 0 : Disabled 1 : Low Current Detection Enabled (Belt Failure / Dry Pump / Broken Impeller) 2 : High Current Detection Enabled (Pump Blockage)

  • Page 52: Fire Mode

    Par. Name Minimum Maximum Default Units P8-14 Pump Staging Function Select Parameter enables the pump staging (cascade) function on the drive. 0 : Disabled 1 : Single VFD with DOL Cascade (max 4 DOL pumps) 2 : Multiple Drive Cascade (Optiflow) Master Drive. (Only valid when drive set to Optibus master address, P5-01 = 1). 3 : Multiple Drive Cascade with Jockey Pump (Optiflow).

  • Page 53: Parameter Group 9 - User Inputs And Output Programming

    9.8. Parameter Group 9 – User Inputs and Output Programming Par. Function Setting Range Default Notes P9-01 Enable Input Source These parameters allow the user to directly select the source of the various command points. Parameters are only adjustable if P1-13 = 0. This allows complete flexibility over the drive control P9-02 Fast Stop Input Source functions, and interaction with the internal Function Block programming environment.

  • Page 54: Parameter Group 0 - Monitoring Parameters (Read Only)

    9.9. Parameter Group 0 – Monitoring Parameters (Read Only) Par. Parameter Name Units P0-01 Analog Input 1 Value Displays the signal level applied to analog input 1 (Terminal 6) after scaling and offsets have been applied. P0-02 Analog Input 2 Value Displays the signal level applied to analog input 2 (Terminal 10) after scaling and offsets have been applied.
  • Page 55 Par. Parameter Name Units P0-23 Time Heatsink >85°C HH:MM:SS Two entry display: First display shows hours. Second display shows minutes and seconds. Displays the amount of time in hours and minutes that the Optidrive has operated for during its lifetime with a heatsink temperature in excess of 80°C.
  • Page 56 Par. Parameter Name Units P0-36 DC Bus Voltage Log (256ms) Diagnostic log for DC bus voltage. Values logged every 256mS with 8 samples total. Logging suspended on drive trip. P0-37 DC Bus Voltage Ripple Log (20ms) Diagnostic log for DC bus voltage ripple. Values logged every 20mS with 8 samples total. Logging suspended on drive trip. P0-38 Heatsink Temperature Log (30s) Diagnostic log for heatsink temperature.

  • Page 57: Serial Communications

    10. Serial Communications 10.1. RS-485 Communications Optidrive Eco has an RJ45 connector located within the wiring enclosure of the drive. This connector allows the user to set up a drive network via a wired connection. The connector contains two independent RS485 connections, one for Invertek’s Optibus Protocol and one for Modbus RTU / BACnet MSTP.

  • Page 58: Modbus Rtu Communications

    Modbus RTU and BACnet MSTP connection should be made via the RJ45 connector. The pin assignments are as shown in section 1 1. 1 . RS-485 communications.  Modbus RTU and BACnet MSTP networks require three conductors for best operation and to eliminate common mode voltages on the drive terminals: o RSR85+ o RS485-...
  • Page 59 Register Read Upper Byte Lower Byte Notes Number Write This register contains 2 bytes. The Lower Byte contains an 8 bit drive status word as follows: Bit 0 : 0 = Drive Disabled (Stopped), 1 = Drive Enabled (Running). Bit 1 : 0 = Drive Healthy, 1 = Drive Tripped. Bit 2: 0 = Auto, 1 = Hand.

  • Page 60: Bacnet Mstp

    10.3. BACnet MSTP 10.3.1. Overview Optidrive Eco provides an interface for direct connection to a BACnet MSTP network. Connection is made via the RJ45 connection port, see section 10. 1 . RS-485 Communications for terminal assignment and section 10. 1 . 1 . RS-485 Communications Electrical Connections for wiring requirements.
  • Page 61 10.3.5. Object Dictionary Binary Value Object: Binary Value Objects Table Instance ID Object Name Access Description Active/Inactive Text Run/Stop State This object indicates drive run status RUN/STOP Trip State This object indicates if drive is tripped TRIP/OK Hand Mode This object indicates if drive is in hand or auto mode HAND/AUTO Inhibit Mode This object indicates drive is hardware inhibit...
  • Page 62 Analog Value Object Analog Value Objects Table Instance ID Object Name Access Description Units Motor Frequency Motor output frequency Hertz Motor Speed Motor output speed (0 if P1-10=0) Motor Current Motor output current Amps Motor Power Motor output power Kilowatts Motor torque Reserved DC Bus Voltage...
  • Page 63 10.3.8. Object/Property Support Matrix Object Type Property Device Binary Value Analog Value Object Identifier × × × Object Name × × × Object Type × × × System Status × Vendor Name × Firmware Revision × Application Software Revision × Protocol Version ×...
  • Page 64 10.3.9. BACnet Protocol Implementation Conformance Statement Date: 15th April, 2015 Vendor Name: Invertek Drives Ltd Product Name: OPTIDRIVE ECO Product Model Number: ODV-3-xxxxxx-xxxx-xx Application Software Version: 2.00 Firmware Revision: 2.00 BACnet Protocol Revision: Product Description: Invertek Optidrive Eco BACnet Standardized Device Profile (Annex L): ...
  • Page 65 Device Address Binding: Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain other devices.)  Yes  No Networking Options:  Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc. ...

  • Page 66: Technical Data

    11.5. Output Power and Current ratings The following tables provide the output current rating information for the various Optidrive Eco models. Invertek Drives always recommend that selection of the correct Optidrive is based upon the motor full load current at the incoming supply voltage.
  • Page 67 11.5.1. 200 – 240 Volt (+/- 10%),1 Phase Input, 3 Phase Output Frame Power Rating Input Fuse or MCB Maximum Cable Size Rated Output Maximum Motor Size Current (Type B) Current Cable Length Non UL AWG/kcmil 0.75 12.9 17.5 19.2 10.5 11.5.2.
  • Page 68 11.5.3. 380 – 480 Volt (+ / - 10%), 3 Phase Input, 3 Phase Output Frame Power Rating Input Fuse or MCB Maximum Cable Size Rated Output Maximum Motor Size Current (Type B) Current Cable Length Non UL AWG/kcmil 0.75 4.
  • Page 69 The rise time and peak voltage can affect the service life of the motor. Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service life.

  • Page 70: 1.6. Additional Information For Ul Compliance

    11.6. Additional Information for UL Compliance Optidrive Eco is designed to meet the UL requirements. For an up to date list of UL compliant products, please refer to UL listing NMMS.E226333. In order to ensure full compliance, the following must be fully observed. Input Power Supply Requirements All the drives in the Optidrive Eco range are suitable for use on a circuit capable of delivering not Short Circuit Capacity...

  • Page 71: 1.7. Internal Emc Filter And Varistors - Disconnection Procedure

    11.7.2. IP55 & IP66 Models These models require disassembly in order to disconnect the EMC filter. Disconnection should be carried out only by Invertek Drives Approved Service Partners. www.invertekdrives.com Version 3.07 | Optidrive Eco User Guide | 71...

  • Page 72: 1.8. Derating Information

    11.8. Derating Information Derating of the drive maximum continuous output current capacity is require when:  Operating at ambient temperature in excess of 40°C / 104°F (IP55 & IP66) or 50°C / 122°F (IP20).  Operating at Altitude in excess of 1000m/ 3281 ft.  Operation with Effective Switching Frequency higher than 8kHz for IP20 models and 4kHz for IP55/IP66 models.

  • Page 73: Troubleshooting

    12. Troubleshooting 12.1. Fault Messages Fault OLED Message Description Corrective Action Code o-Ft No Fault No Fault Displayed in P0-13 if no faults are recorded in the log. - Fault Occurs on Drive Enable Over current trip Instantaneous over current on drive Check the motor and motor connection cable for phase –...
  • Page 74 A historical log is stored at 20ms intervals prior to a trip in parameter P0-37. Check all three supply phases are present and within the 3% supply voltage level imbalance tolerance. Reduce the motor load. If the fault persists, contact your local Invertek Drives Sales Partner. P-o Input phase loss Input phase missing...
  • Page 75 Fault OLED Message Description Corrective Action Code Ph-SEq Incorrect Supply L1-L2-L3 Phase Applies to Frame Size 8 drives only, indicates that the incoming power supply Phase Sequence sequence is incorrect phase sequence is incorrect. Any 2 phases may be swapped. P-o Feedback Pressure Low Pressure...
  • Page 76 Ñ82-HEMAN-IN_V3.07wÓ 82-HEMAN-IN_V3.07 Invertek Drives Ltd. Offa's Dyke Business Park, Welshpool, Powys SY21 8JF United Kingdom Tel: +44 (0)1938 556868 Fax: +44 (0)1938 556869 www.invertekdrives.com...
