Par Parameter Name
P2-15 Relay 1 Function
Digital Output Mode. Logic 1 = +24V DC
Selects the function assigned to Relay Output 1. The relay has normally open and normally closed contacts. Logic 1 indicates the
relay is active, and therefore the normally open contact is closed (terminals 14 and 15 will be linked together) and the normally closed
contact is opened (terminals 14 and 16 will no longer be connected together).
Settings 4, 5, 6, 7 & 14 use the adjustable limit parameters P2-16 and P2-17. The Output switches to Logic 1(24 Volt DC) when the
chosen analog value exceeds the Upper Threshold (P2-16) and resets to Logic 0 (0 Volt DC) when the chosen analog value reduces
below the Lower Threshold (P2-17).
0 : Drive running. Logic 1 when the motor is enabled.
1 : Drive healthy. Logic 1 when power is applied to the drive and no fault exists.
2 : At speed. Logic 1 when the output frequency matches the set-point frequency.
3 : Motor speed > 0. Logic 1 when the drive output frequency to the motor is exceeds 0.0Hz.
4 : Motor speed >= limit. Logic 1 when the motor speed exceeds the adjustable limit.
5 : Motor current >=limit. Logic 1 when the motor current exceeds the adjustable limit.
6 : Motor Torque >=limit. Logic when the motor torque exceeds the adjustable limit.
7 : Analog input 2 >=limit. Logic 1 when the signal applied to the Analog Input 2 exceeds the adjustable limit.
8 : Reserved. No Function.
9 : Fire mode active. Logic 1 when the drive in running in Fire Mode (Fire Mode input is active).
10 : Maintenance due. Logic 1 when Maintenance Timer expires indicating that Maintenance is now due.
11 : Drive ready to run. Logic 1 when drive is in Auto-mode, no trips are present, and the safety circuit is enabled indicating that
drive is ready for automatic control.
12 : Drive tripped. Logic 1 when the drive has tripped and the display shows the fault code.
13 : STO Status. Logic 1 when both Hardware Enable (STO) inputs are present and the drive is able to be operated.
14 : PID error >=limit. The PID Error (difference between setpoint and feedback) is greater than or equal to the programmed limit.
15 : Low & high current warning. Logic 1 when the load monitoring has been enabled using P8-06 to P8-08 and a high load
or low load condition has been detected – usually used to signal pump blockage or burst pipe.
P2-16 Relay 1 / AO1 Upper Limit
Setting the upper limited value for P2-1 1 and P2-15, please refer to P2-1 1 or P2-15.
P2-17 Relay 1 / AO1 Lower Limit
Setting the lower limited value for P2-1 1 and P2-15, please refer to P2-1 1 or P2-15.
P2-18 Relay 2 Function
Selects the function assigned to Relay Output 2. The relay has two output terminals, Logic 1 indicates the relay is active, and therefore
terminals 17 and 18 will be linked together.
Settings 4, 5, 6, 7 & 14 use the adjustable limit parameters P2-19 and P2-20. The Output switches to Logic 1(24 Volt DC) when the
chosen analog value exceeds the Upper Threshold (P2-19) and resets to Logic 0 (0 Volt DC) when the chosen analog value reduces
below the Lower Threshold (P2-20).
0 : Drive running. Logic 1 when the motor is enabled.
1 : Drive healthy. Logic 1 when power is applied to the drive and no fault exists.
2 : At speed. Logic 1 when the output frequency matches the set-point frequency.
3 : Motor speed > 0. Logic 1 when the drive output frequency to the motor exceeds 0.0Hz.
4 : Motor speed >= limit. Logic 1 when the motor speed exceeds the adjustable limit.
5 : Motor current >=limit. Logic 1 when the motor current exceeds the adjustable limit.
6 : Motor torque >= limit. Logic 1 when the motor torque exceeds the adjustable limit.
7 : Analog input 2 >=limit. 1 Logic when the signal applied to the Analog Input 2 exceeds the adjustable limit.
8 : Assist pump 1 control (DOL*). See section 7. 1 , Pump staging –DOL Cascade.
9 : Fire mode active. Logic 1 when the drive in running in Fire Mode (Fire Mode input is active).
10 : Maintenance due. Logic 1 when Maintenance Timer expires indicating that Maintenance is now due.
11 : Drive ready to run. Logic 1 when drive is in Auto-mode, no trips are present, and the safety circuit is enabled indicating that
drive is ready for automatic control.
12 : Drive tripped. Logic 1 when the drive has tripped and the display shows the fault code.
13 : STO status. Logic 1 when both Hardware Enable (STO) inputs are present and the drive is able to be operated.
9
14 : PID error >=limit. The PID Error (difference between setpoint and feedback) is greater than or equal to the programmed limit.
15 : Low & high current warning. Logic 1 when the load monitoring has been enabled using P8-06 to P8-08 and a high load
or low load condition has been detected – usually used to signal pump blockage or burst pipe.
P2-19 Relay 2 / AO2 Upper Limit
Setting the upper limited value for P2-13 and P2-18, please refer to P2-13 or P2-18.
P2-20 Relay 2 / AO2 Lower Limit
Setting the lower limited value for P2-13 and P2-18, please refer to P2-13 or P2-18.
42 | Optidrive Eco User Guide | Version 3.05
Minimum Maximum
0 14
P2-17 200.0
0 P2-16
0 14
P2-20 200.0
0.0 P2-19
Default Units
1 -
100.0 %
0.0 %
0 -
100.0 %
0.0 %
