Videx 4000 Series Technical Manual page 55

4000 Series GSM Audio Intercom with Proximity
Programming the GSM Intercom
The following example shows how to program an access code:
Example:
Programming a 4 digit access code of 4321, storing it in memory location 001 and to activate relays 1 and 2, the following
text can be sent to the GSM PRO intercom:
Note that in this example no commas , are required to separate the relay selections and a ? has been included to
receive a confirmation text. The GSM PRO intercom will reply with the following text:
Expanding on the PIN programming command it is also possible to store an access code into the next available memory location.
This is particularly useful when programming additional codes into a GSM PRO intercom where there are already existing access
codes programmed, but the locations of where they are stored is unknown. Using the PIN programming text string, but omitting
the nnn (000 - 399) memory location from the command the following texts can be used to program access codes to the next free
memory location and confirm where the code will be stored.
1111PIN"code"12
1111PIN"code"12?
The following example shows how to program an access code into the next free memory location:
Example:
If there are several access codes already programmed into the GSM PRO from memory locations 000 - 094, but the user
didn't know they were programmed into these locations and where an 8 digit access code of 12345678 was required to
activate relay 2 only, then the following text can be sent to the GSM PRO intercom:
Note that in this example no comma , is required to separate the relay selection and a ? has been included to receive
a confirmation text. The GSM PRO intercom will reply with the following text:
In this example the reply from the GSM PRO shows that the access code 12345678 is stored in memory loaction 095,
which is the next available memory location after 094.
STORE AN ACCESS CODE WITH AN ACCESS LEVEL (PIN) INCLUDING RELAY SETUP
Expanding further on the PIN programming command an access level can also be assigned to the access code. Using the same PIN
command as before the access level number An (from 0 - 9) is included at the end of the programming command. The following
codes can be used to either store a code with an access level in a known location (000 - 399) or store a code with an access level in
the next available location (also see examples below).
1111PINnnn"code"An
1111PINnnn"code"An?
1111PIN"code"An
1111PIN"code"An?
Example 1: Programming an access code of 654321, storing it in memory location 008 and assigning it to access level A4, the
following text can be sent to the GSM PRO intercom:
Including a ? at the end of the programming command the GSM PRO intercom will reply with the following text:
In this example the 6 digit access code will be stored in memory location 008 and will automatically be setup to
trigger relay 1 and the code assigned to access level 4.
Example 2: Programming an access code of 15432, storing it to the next free memory location (if locations 000 - 125 are
occupied) and assigning it to access level A3, the following text can be sent to the GSM PRO intercom:
4000 Series GSM Audio Intercom - Technical Manual
1111PIN001"4321"12?
PIN 001=4321,12
OK VIDEX GSM
Store access code in the next memory location available, where code = 4 - 8 digit access
code and the number 1 and/or 2 is the relay to activate.
Store access code in the next memory location available, where code = 4 - 8 digit access
code and the number 1 and/or 2 is the relay to activate. Also send a confirmation text back
to the sender with details of where code is stored and which relays will be activated.
1111PIN"12345678"2?
PIN 095=12345678,2
OK VIDEX GSM
Store access code in location nnn and assign access level An, where nnn = memory
location 000 - 399 where the access code is stored, where code = 4 - 8 digit access code
and where An is the access level = A0 - A9.
As above and also send a confirmation text back to the sender with the location of where
the code is stored and the access level it is assigned to.
Store access code in the next free location and assign access level An, where code = 4 - 8
digit access code and where An is the access level = A0 - A9.
As above and also send a confirmation text back to the sender with the location of where
the code is stored and the access level it is assigned to.
1111PIN008"654321"A4?
PIN 008 = 654321,1,A4
OK VIDEX GSM
- 55 -
66250754-EN - V1.0 - 18/02/19
