4000 Series
Art. 4534
Speaker unit with built-in camera for IPure system
Art. 4534X
A
B
C
D
Fig. 1 Front
DESCRIPTION
Speaker unit module for IP system with built-in Wide Angle co-
lour camera with white light illumination LEDs. Depending on
the speaker unit version it can include zero, one or two call push
buttons.
Art.  4534X versions are also equiped with a built-in proximity
key reader.
Hardware features:
• The transmitting amplifier and microphone.
• The receiving amplifier.
• Two relay outputs to enable electric lock and an additional
service (3 contacts each: common, normally open and nor-
mally closed).
• The call buttons from 0 to a maximum of 2 depending on the
module version.
• The illumination LEDs for the card name holder.
• The camera and illumination LEDs.
To download the programming software
VX IP Wizard and obtain the latest firmware
and manuals please visit the following web-
site and register
https://service.videx.it/
Art. 4534 - 4534X - Installation instructions
Speaker unit with built-in camera & proximity key reader for IPure system
B
Capacitor
discharge
Dry contact
output
M
E
N
Fig. 2 Back
LEGEND
Camera with illumination
A
LEDs
Operation LEDs
B
Loudspeaker
C
Card name holder with
D
built-in proximity key
reader (only Art. 4534X
versions)
Call push button
E
AVAILABLE VERSIONS
Art. 4534-0
Art. 4534X-0
LEDS
Flashes when the called indoor station is busy.
The LED will be off when the system is in stand-by.
If illuminated, indicates that the call from the outdoor sta-
tion is in progress. The LED will switch OFF when the call is
answered or the call ends due to timeout.
If illuminated, indicates that it is possible to speak be-
cause the call has been answered. The LED will switch
OFF at the end of a conversation (or at the end of the
conversation time).
If illuminated, indicates that the door lock has been op-
erated. It will switch OFF at the end of the programmed
"door opening" time.
- 1 -
4534X
Audio/video speaker unit
for IPure system
Made in Italy
PROG.
RJ45
RS-485
OPEN
CLOSE
RELAY 1 RELAY 2
WIEGAND
INPUTS POWER
EXPANSION BUTTONS
Boot loader push button
F
for firmware update
POE Ethernet interface
G
RS485 termination switch
H
RS485 connection terminals
I
Button expansion
L
modules connector
Door open relay operating
M
mode jumper
Connection terminals
N
1
Art. 4534-1
Art. 4534X-1
66252030 - V 1.1 - 31/03/22
F
G
H
I
L
2
1
Art. 4534-2
Art. 4534X-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Videx 4000 Series

  • Page 1 4000 Series Art. 4534 Speaker unit with built-in camera for IPure system Art. 4534X Speaker unit with built-in camera & proximity key reader for IPure system 4534X Audio/video speaker unit for IPure system Made in Italy PROG. RJ45 RS-485 OPEN CLOSE Capacitor...
  • Page 2: Operation

    In case of firmware update failure (i.e. because of mains failure or cable disconnection during the update etc.) and the door panel is no longer recognised by the Videx IP Wizard software, you can try to restore it by manually putting it into boot mode.
  • Page 3 4000 Series Art. 4534 Speaker unit with built-in camera for IPure syetem Art. 4534X Speaker unit with built-in camera & proximity key reader for IPure system CAMERA NOTES PRECAUTIONS ON THE CAMERA • Please note that OPENING THE MODULE WILL INVALIDATE THE WARRANTY. In addition, any dust ingress could COMPROMISE THE IMAGE QUALITY.
  • Page 4: Technical Specification

    4000 Series Art. 4534 Speaker unit with built-in camera for IPure syetem Art. 4534X Speaker unit with built-in camera & proximity key reader for IPure system CONNECTION TERMINAL SIGNALS TECHNICAL SPECIFICATION NO1 Relay 1 normally open contact Video codec: H.263 H.263+ RELAY 1 NC1 Relay 1 normally closed contact H.264...
  • Page 5: Versioni Disponibili

    Art. 4534X-1 Art. 4534X-2 meni di firmware e manuali è necessario regi- strarsi sul sito web https://service.videx.it/ Lampeggia quando il posto interno chiamato è occupato. Si spegne quando il sistema entra in stand-by. Se acceso indica che è in corso una chiamata.
  • Page 6: Funzionamento

    Nel caso di aggiornamento del firmware non riuscito (ad esempio a causa di una caduta di tensio- ne o a casusa dello scollegamento del cavo durente l’aggiornamento ecc.) e l’unità non viene più riconosciuta dal software Videx IP Wizard, è possibile resettare l’unità manualmente abilitando la modalità bootloader.
  • Page 7 Serie 4000 Art. 4534X Portiere elettrico con telecamera e lettore di prossimità incorporati per sistema IPure NOTE TELECAMERA PRECAUZIONI SULLA TELECAMERA • Si ricorda che L’APERTURA DEL MODULO NE INVALIDA LA GARANZIA. Inoltre l'eventuale ingresso di polvere potrebbe COMPROMETTERE LA QUALITÀ DELL’IMMAGINE. •...
  • Page 8: Specifiche Tecniche

    Serie 4000 Art. 4534X Portiere elettrico con telecamera e lettore di prossimità incorporati per sistema IPure SEGNALI MORSETTERIA DI CONNESSIONE SPECIFICHE TECNICHE NO1 Relé 1 contatto normalmente aperto Codec video: H.263 H.263+ RELAY 1 NC1 Relé 1 contatto normalmente chiuso H.264 Relé...
  • Page 9 Switch PoE Switch PoE Switch PoE 2505 2505 Rif.SLD_IPURE_V_001 - 9 - 66252030 - V 1.1 - 31/03/22...
  • Page 10 - 10 - 66252030 - V 1.1 - 31/03/22...
  • Page 11 DISPOSAL In accordance with the Legislative Decree no. 49 of 14 March 2014 “Implementation of the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE)”. The crossed-out bin symbol on the equipment or on the packaging indicates that when the product reaches the end of its lifetime, it must be collected separately from mixed municipal waste.
  • Page 12 MANUFACTURER VIDEX ELECTRONICS S.P.A. FABBRICANTE Via del Lavoro, 1 FABRICANT 63846 Monte Giberto (FM) Italy FABRICANTE Tel (+39) 0734 631669 FABRIKANT Fax (+39) 0734 632475 www.videx.it - info@videx.it FABRICANTE ‫ال� ش كة المص ن ِّ عة‬ CUSTOMER SUPPORT VIDEX ELECTRONICS S.P.A.
