• Confi guring the monitor

◊ VIP address

This menu can be used to confi gure the VIP address of the internal unit.
CONFIGURE MONITOR
Configure ViP address
Master
Slave
1. Access the Confi gure VIP address menu to set the address of the
device.
2. Select whether to set the device as Master or Slave. If you select
Slave, you will also need to set the exact number.
Master
By Master we mean the main internal unit in an apartment. Every
Master internal unit in the system must have a different VIP code. The
Master internal unit manages all external unit / switchboard / intercom
calls. It is essential that, in an apartment, one of the internal units is set
as a Master.
Slave
By Slave we mean one or more secondary internal units (MAX. 15) in
an apartment. Each Slave has the same VIP address as the Master
internal unit.

◊ About

This menu can be used to view system data.
CONFIGURE MONITOR CONFIGURE MONITOR
MAC: 00:25:34:08:00:DC
ViP address ViP address
IP: 169.254.241.41 (A/16)
GW: 0.0.0.0
ID: 00000001, SUB: 0
About About
SW: 1.5.3

Reset configuration

Reset configuration
64
1
OK
◊ Reset confi guration
This function can be used to restore the factory set values of the monitor,
deleting all confi gurations applied in the meantime.
CONFIGURE MONITOR CONFIGURE MONITOR
ViP address ViP address
Continue?
About About
Reset configuration Reset configuration
CONFIRM

• Special Settings

◊ Actuator Directory

This menu can be used to manage the directory of actuators connected
to the system.
ACTUATOR DIRECTORY
Actuator 1
Abc
C
1. Access the Actuator setting menu by pressing the + icon to add a
new device to the directory.
ACTUATOR SETTING
Configure Name
Configure ViP Address
Module
Output
2. Access the Confi gure Name menu to associate the actuator with the
name which will appear in the directory.
3. Access the Confi gure VIP address menu to enter the address of the
actuator module Art. 1443.
4. In the module fi eld, select whether to control the relay on board the
module itself (255) or one on board an expansion module connected
to it (1 to 10).
5. In the output fi eld, select the exact relay you wish to control. 1 or 2
for relays on board the module art.1443, or 1 to 10 for relays of an
expansion module connected to it.
CANCEL
255
1
