Comelit Venice Wi-Fi Technical Manual

Venice Wi-Fi
6854W
T E C H N I C A L M A N U A L
Venice Wi-Fi door entry
monitor - ViP system
Android door entry monitor
the Comelit IP video entry system (ViP), with 7"
touchscreen and the same flexibility as a tablet with
the possibility to load third party apps. The apps
must be verified and certified by Comelit to guarantee
compatibility and to allow them to load. This means
the user is offered a device which is no longer just
a door entry monitor, but a controller for the home
that can be used to manage the functions offered
by systems from other manufacturers, for example
managing home automation, intruder alarm and
building services, plus accessing web pages and
using pre-installed apps. The device has a LAN port
and Wi-Fi connection to guarantee IP video entry
system connection and the Internet connection
required to use the installed apps.
Technical specifications
GENERAL DATA
Product height (mm) 130
Product width (mm) 194
Product depth (mm) 15,9
Product color White
Material Plastic
Wall-mounted Yes
DISPLAY FEATURES
Size (inches) 7
Aspect Ratio 16:9
Touch screen Yes, capacitive
Resolution (pixels) 1024x600
OSD menu Yes
Type of display LCD
compatible with
with art. POESPLITTER
Absorption in stand-by 4,5 Watt
HARDWARE FEATURES
IP address assignment DHCP, AUTO IP, static IP
AUDIO FEATURES
Tech. implemented Full-Duplex
ELECTRICAL
CHARACTERISTICS
Type of power supply PoE, External power
supply
Supply voltage 18-24 VDC
Supply voltage
12 VDC (max 1mt)
PoE power supply SPoE (24 VDC)
Maximum absorption 7 Watt
Number of inputs 4
Communication ports RJ45 (Ethernet)
Ethernet ports 1
Network connection RJ45
Type of connections/ 1xEthernet 10/100
ports Mbit/s
Video encoding H.264
SETTINGS
Loudspeaker volume Yes
Microphone volume Yes
Ringtone volume Yes
Screen brightness Yes
Screen contrast Yes
Screen colour Yes
Screen backlight Yes
NETWORK AND
COMMUNICATION
PROTOCOLS
Type of LAN network Ethernet 10/100 Mbit/s
Operating system Android
