Powercom series external units

Powercom module Art. 3331/0 - 1 - 2 for audio/video units

Module designed for audio/video speaker units. Requires audio/video unit Art. 4662C to complete installation. Versions with 0, 1 and 2 buttons are
available.

Powercom series colour audio/video unit for VIP system Art. 4662C

VIP system audio-video unit with terminal block, complete with spherical lens adjustable colour camera.
For wiring details, refer to the diagrams section at the end of this manual.

Powercom call button module Art. 3337/3 - 4 - 6

Additional call button module. Versions with 3, 4 and 6 buttons are available.
For wiring details, see page 28.
12
1
1. 4-pole cable connector
Technical characteristics
Power supply
Temperature thresholds
Dimensions
NC / NO: Door lock connection terminals
COM: Common terminal
DO: Door Open terminal
RTE / -: Timed relay control terminals
~ ~: Power supply terminals
TX- / TX+: Ethernet transmission line terminals
RX- / RX+: Ethernet reception line terminals
12 Vac
-30 / +55°C
H: 10.2 cm W: 5.5 cm D: 3.5 cm
