Chapter 5: Installation programming

Mac Address

Every VIP product is identified by the factory with a unique code called the Mac address. The Mac address for the product is indicated by a label on the
packaging box and another label applied directly to the product itself.

VIP code

Each system device must be programmed with a different code, called the VIP address. The VIP address is an 8-digit code identifying each extension
and can be entered as desired, without following any pre-set sequence. However, we recommend using a logic diagram to keep track of the addresses
entered.
A logic diagram (optional) for entering the VIP address is provided below.
Example : Building/staircase/floor/apartment
• 01041156
• 00021022
• 01001223
• 01030009
• 00000012
During the installation of various products, we recommend a document is compiled to keep track of the location of the device within the
system.
An example of how to compile such a document is provided below:
Mac Address
00252900082B
00252900086C
00252900023R
00252900052A
* For all products, the VIP address is programmed using VIP Manager software Art. 1449, with the exception of monitors Art. 6202 and Art. 5900, which
can be used to set the VIP address, even locally.

Reset procedure for external unit Art. 4662C and 4682C

1. Cut off the power supply to the external unit.
2. Enable programming mode by moving the relevant slider.
3. Set the dip switch activation code: dip switches 1-2-3 to ON, the other dip switches to OFF.
4. Restore the power supply to external unit.
5. The external unit will now beep twice to request the confirmation code.
6. Set the dip switch confirmation code: dip switches 1-2-3 to OFF, the other dip switches to ON (i.e. the opposite of the activation code).
7. Exit programming mode by moving the relevant slider.
8. The external unit will now beep for 2-3 seconds to indicate that the configuration has been reset.
9. When the beep has ended, the external unit will start up with its factory set configuration values.
44
VIP Address *
00002001
00002002
00000139
00000127
Description
South gate external unit
North gate external unit
Apartment 1 internal unit
Smith apartment internal unit
