Venice
Android Wi-Fi
6944B, 6944W
T E C H N I C A L M A N U A L

Advertisement

loading
Need help?

Need help?

Do you have a question about the Venice and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comelit Venice

Summary of Contents for Comelit Venice

  • Page 1 Venice Android Wi-Fi 6944B, 6944W T E C H N I C A L M A N U A L...

  • Page 2: Technical Specifications

    IP address assignment DHCP, AUTO IP, static IP Operating system Android entry monitor - ViP system ENVIRONMENTAL AND COMPLIANCE FEATURES Venice XL Wi-Fi colour door entry monitor for ViP IP protection degree IP30 system with Android operating system. 10” capacitive Operating temperature -20° ÷ +55°...

  • Page 3: Operating Distances

    1. LCD Display · Touch screen · 10” 16:9 · Pixel 1280x800 2. Microphone 3. 2 magnets for fixing the door entry monitor to the bracket 4. RJ45 SPOE (24 VDC) to connect art. 1442B 5. Power input (18-24 VDC) as an alternative to SPOE power supply 6.
  • Page 4 Welcome Deutsche Confi guration 4. Set the ViP address for the device (8-character English alphanumeric ID code provided by your installer) CONFIGURATION WIZARD and choose whether you want to install the Español monitor as: 1. Select the desired language, confi rm by pressing •...

  • Page 5: Basic Wiring Diagram

    Basic wiring diagram 1442B 100-240 V Use POE ports to connect the art. 1442B 6944B, 6944W 100-240 V 6944W 6944B 6944W 6944B ORANGE WHITE ORANGE GREEN WHITE GREEN 6944W 6944B 1595 120-230 V TX TX RX RX NO NC UT8020 UT9200 20 m max.
  • Page 6 Variant with second external unit 1442B 100-240 V 1442B 100-240 V Use POE ports to connect the art. 6944B, 6944W Connections among uplink ports and 1440 only with Comelit red cable 1449 6944W 6944B ORANGE WHITE ORANGE GREEN 6944W 6944B WHITE GREEN...
  • Page 7 Variant with PoE standard switch 1442B 100-240 V Use POE ports to connect 1442B the art. 6944B, 6944W 100-240 V 6944W 6944B 6944W 6944B 6944W 6944B STANDARD SWITCH BROWN & WHITE BROWN BLUE & WHITE BLUE ORANGE WHITE ORANGE GREEN WHITE GREEN 12 VDC 0,25A...
  • Page 8 C E R T I F I E D M A N A G E M E N T S Y S T E M S w w w . c o m e l i t g r o u p . c o m 3nd edition 07/2024 Via Don Arrigoni, 5 - 24020 Rovetta (BG) - Italy code 2G40003285...

This manual is also suitable for:

6944b6944w
