• Programming the VIP code for main
Planux monitors
1. Access the installer menu.
2. Select the Confi gure monitor menu using buttons
INSTALLER MENU
Configure monitor
3. Press to access it.
CONFIGURE MONITOR
ViP address
About
Reset configuration
4. Press button to access the VIP address menu.
5. Change the address using buttons
from one digit to the next.
CONFIGURE VIP ADDRESS
ViP address
0 0 0 0 0 0 0 1
Master
Slave 0 0
Left Right
, .
, . Use buttons , to pass
• Programming the VIP code for secondary
Planux monitors
1. Access the installer menu.
2. Select the Confi gure monitor menu using buttons
INSTALLER MENU
Configure monitor
3. Press to access it.
4. Press button to access the VIP address menu.
CONFIGURE MONITOR
ViP address
About
Reset configuration
5. Set the logic address for the main monitor in the same residential
unit using buttons , . Use buttons
to the next.
CONFIGURE VIP ADDRESS
ViP address
0 0 0 0 0 0 0 1
Master
Slave 0 0
Left Right
6. Move over the Slave option using buttons
confi rm.
CONFIGURE VIP ADDRESS
ViP address
0 0 0 0 0 0 0 1
Master
Slave 0 0
Left Right
7. Move over the Slave address option using buttons
change the address using buttons
CONFIGURE VIP ADDRESS
ViP address
0 0 0 0 0 0 0 1
Master
Slave 0 1
Left Right
, .
, to pass from one digit
, and press to
, and
, .
