7. Press button
to return to the previous menu.
CONFIGURE DIRECTORY
Configure name
Configure ViP address
8. Select the Confi gure VIP address menu by pressing
press
to access it.
9. Select the fi elds which can be changed using
value using
,
or
.
ACTUATOR SETTING
Active:
ViP address:
0 0 0 0 0 1 0 1
Module 255
Output
0 1
Left
Right
• The VIP address fi eld identifi es actuator module Art. 1443.
• In the Module fi eld, select whether to activate the relays on board
the module (255) or those on the expansion module Art. SK9071
connected to it (1 to 10) .
• In the Output fi eld, select the relay you intend to activate : 1 or 2 if
you enter 255 in the module fi eld, or 1 to 10 if you enter an expansion
module in the module fi eld.
10. Press
to exit and save the changes.
• Setting the Door Open function
The function can be used to monitor the input of an external unit
programmed with the Door Open function. When the input is opened
or closed the key LED on the monitor lights up to indicate that the door
is open.
1. Access the installer menu.
2. Select the Special Settings menu by pressing
to access it.
,
and
,
and change the
3. Select the Door open menu by pressing
access it.
4. Press the
5. Select the fi elds which can be changed using
value using
• The VIP address fi eld identifi es the external unit you wish to
monitor.
6. Press
INSTALLER MENU
Special Settings
SPECIAL SETTINGS MENU
Call
Self-ignition
Actuator
Door open
Alarms
Set ringtone repetition
button.
DOOR OPEN
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Not assigned
Edit
,
or
.
CONFIGURE VIP ADDRESS
Active:
ViP address:
0 0 0 0 0 1 0 1
Left
Right
to exit and save the changes.
,
and press
,
and press
to
,
and change the
57
