Section 1
Introduction
This diagnostic tool is a specialized personal automotive diagnostic solution that
combines information with test instrumentation to help you diagnose symptoms,
codes, and complaints quickly and efficiently. There are three main components to
the system:
Diagnostic
Tool-central processor and display for the system
•
Scope
Module-oscilloscope/meter module used to measure circuits and
•
signals
Compact Scan
Module-wireless module used to access vehicle data
•
The Scope Module and Compact Scan Module are described in their applicable
sections within this manual.
