Scope and Multimeter Operations

8.64.2 Control Panel (Trace Controls Quick Reference)

Trace (channel) settings and controls can be accessed in the Control Panel and the
Trace Setup menu. Graphic and value icons are used in the control panel to access
the settings. Applicable settings are displayed depending on the test.
Various control icons are shown in the following images, select a callout description
(blue text) to link to that topic.
1.

Profile Icon

2.
Channel Icon on page 111
3. Probe Icon
4. Peak Detect Icon
5. Filter Icon
6. Invert Icon
7. Coupling AC Icon
8. Slope (Trigger) Icon
9. Snapshot Icon
10. Expand/Collapse Icon - see
Display Modes
11. Trigger Setup Menu Icon - see
Trigger Setup Menu
Figure 8-32
Scale (Vertical / Y-axis)
12.
Cursor Indicators - see
13.
Zero Baseline Indicators - see
14.
Zero Baseline Adjustment
Sweep Scale (X-axis)
15.
8.64.3 Profile Icon
The Profile icons (variable) allow you to hide or display channels
onscreen.
Selecting an icon turns a channel on and off.
On (Channel displayed)
110
Control Panel and Settings
Channel Scale Indicator Icons -
16.
Scale (Vertical / Y-axis)
Cursors see
17. Sweep Indicator Icon - see
Scale (X-axis)
18. Min, Live and Max Display Panel
19. Cursor Control Panel - see
Cursor Measurements Panel
Figure 8-33
Profile Icons (Typical)
Off (Channel not displayed)
Sweep
