6. Fill in all customer and vehicle information fields as required
7. In the Jobs section of the form, select the applicable shop labour rate from the
dropdown box (Figure
9-24).
NOTE
You may set up to three custom labour rates. To setup shop labour rates,
select the Settings dropdown box from the main screen and then select
Preferences. Scroll down to the Financial Settings section to Labour Rates
and VAT Rates. You may setup three labour rates and three VAT rates with
custom names. Select Save when finished. These custom rate options are
displayed in the dropdown boxes on the Cost Estimate form
NOTE
All editable value fields on the form may be changed manually. Select the field
to make a change. Enter all applicable values using a decimal point.
8. Enter a time margin percentage if needed
number will either increase or decrease the built-in "Time(h)" by the
percentage entered. To enter a negative percentage (decrease %) enter "-"
(e.g. -10.0).
9. In the Parts section of the form
10.Choose the applicable VAT rate
Preferences, see note above).
11. When completed, select Save
The Work Order manager screen displays
saved work orders. To open/edit a work order, select it from the list. Search and
sort functions are provided to quickly find a record.
To view a saved work order after starting a new session, see
Previously Selected Vehicle or Open a Saved Work Order
(Figure
(Figure
(Figure 9-24). The entered
(Figure 9-24). make any needed changes.
(Figure 9-24). (As defined in Settings >
(Figure
9-24).
(Figure 9-25). This is a list of all
To Choose a
on page 141.
9-24).
9-24).
9.7

Electronics

Selecting the electronics tab, displays a submenu of all available vehicle electrical
reference and testing information.
Submenu options may include the following:
All Electronic Systems
•
Engine
•
Steering and Suspension
•
Brake
•
Exterior/Interior
•
Fuses and Relays
•
Locations
•
Electronic Procedures
•
Warning Lights and Indicators
•
NOTE
To access the Electronics screen at anytime, select Electronics from the main
menu panel.
147
Figure 9-25
Electronics
