Guided Component Tests

7.51.2 Menu Icon

Selecting the Menu icon from the lower toolbar provides the
following options:
Safety Information—opens the Important Safety Instructions document. See
•
on page 1 for additional information.
Safety Information
See
File on page 84
•
Help—provides a link to open this user manual. See
•
additional information.
File
Selecting File opens a menu of print options (see
page 19):
Print Article—selecting has one of two results:
•
If a printer is connected, the file is sent to the printer.
–
If a printer is not connected, the article is saved as a (.xps) file, which can be
–
retrieved, moved, or copied and printed at a later time.
Print Preview—opens a representation of what the printed file will look like.
•
Page Setup—allows you to adjust margins and paper orientation.
•

7.51.3 Training and Classes

Training and Classes is a companion feature to the Guided Component Tests
function and can be selected from the vehicle make menu
Training and Classes. This resource includes a wide collection of common (non-
vehicle specific) reference information and tests, such as measuring fuel pump
current ramp, and monitoring CKP and CMP signals simultaneously. Also included
are; basic component operation and theory information, testing procedures, tips,
definitions, illustrations, diagnostic tool feature descriptions, and accessory
information.
on page 171 for
Help
Printing / Printer Setup on
(Figure 7-3), select
84
Selecting Training and Classes provides the following options (each option is
described in the following sections):
Power User Tests
•
How To Guide
•
Features and Benefits
•
NOTE
The information listed in the following sections is not inclusive, actual content
may vary.
Power User Tests
Power User Tests provide you quick access to preconfigured meter tests for a
number of common automotive system tests. Most tests provide onscreen help and
testing information along with a description of the test and the expected results,
including known good waveforms.
Here is a sample listing of the types and specific tests that may be available within
Power User Tests:
Current Probe Tests - provides common tests configured to use the Snap-on
•
Low Amp Current probes or generic Low Amp Current probes. Snap-on Low
Amp Current Probe operation information is also provided within the Snap-on
Low Amp Probe Reference Manual option.
• Fuel Injector Current Ramp (multiple types)
General Information
Figure 7-3
