Snap-On ZEUS User Manual page 114

Scope and Multimeter Operations
Units
Selecting Units opens the Setup dialog box. The units of measurement can be
changed between US customary or metric. The selected radio knobs on the Setup
dialog box show which settings are active
Figure 8-26 Sample Setup Units dialog box
Abbreviation
bar bar
inHg inches of mercury
kg/cm2 kilograms per centimeter squared
kPa kilopascal
mmHg millimeters of mercury
psi pounds per square inch
(Figure
8-26).
Description
Snapshot
The Snapshot tab opens a menu
data is captured after a snapshot is initiated. Make a (%) selection, then select
Back or Exit to close the dialog box.
See on page 124 for information on using the snapshot feature.
Snapshot Icon
107
Setup Menu (Preferences)
(Figure 8-27) that allows you to select how much
Figure 8-27
