  • Page 1 ZEUS ™ GE TTI NG STARTED PAC K diagnostics.snapon.com/zeus...
  • Page 2 Getting Started 1. Align the tabs on the battery pack with the slots in the battery compartment, then pivot the battery pack down into position, until seated. 2. Tighten the screws. Note - Do not overtighten the screws. 3. Connect the AC power supply, to charge the battery.
  • Page 3 Features Button Shortcut Button Press the button for 3 seconds to open the Shortcut menu. button menu allows you to set the button to automatically perform routine functions, like capturing a screenshot, or opening the virtual keyboard. Touch Power (On/Off) Speaker Screen Button...
  • Page 4 Scanner Scanner makes vehicle communication easy, by providing full Intelligent Diagnostics Data Graphing - View up to 16 graphs at once for data comparison analysis Code Scan - Scan multiple systems and check readiness monitors in a single touch Tests/Resets - Perform functional component tests, and adaptive relearns Scanner Basics 1.
  • Page 5 Intelligent Diagnostics Interactive Demonstration From the Scanner Demo select Engine > Codes Menu > (previous page) Display Codes > DTC Display, then follow along with the Intelligent Diagnostics demo screens to get familiar with all the features. Example - Intelligent Diagnostics Demo Main Menu...
  • Page 6 Intelligent Diagnostics Smart Data Smart Data will help you focus on troubleshooting the code, by displaying a custom list of (upper/lower limits set) and armed. PIDs that exceed these limits display a ATTENTION : Smart Data is intended to be used while the vehicle is at idle and at norm ST Trim-1 LT Trim-1 MAF(Hz)

  • Page 7: Repair Information

    ShopKey Pro, is a complete repair information system comprised of multiple modules providing you easy access to OEM repair, estimating, maintenance, as well as real-world experience-based information, Contact your Snap-on representative to learn more about ShopKey Pro, or ® visit ShopKeyPro.com...

  • Page 8: Guided Component Tests

    Guided Component Tests instructions to help you verify component integrity and validate repairs. Vehicle information may include: • Component testing instructions and locations • Waveform examples • Illustrated connectors with pinouts • Diagnostic references CKP Sensor Signal Test (Example) 1. Select Guided Component Tests from the Home screen. 2.

  • Page 9: Customer Support

    Contact your local Snap-on representative for information. Software Subscription Program Snap-on is continually enhancing our diagnostic software to provide our customers with the latest information available, not only for new vehicles but for older vehicles as well. The Snap-on Software Subscription Program is the no-hassle, low-cost way to automatically get the latest codes, data, tests and exclusive coverage for thousands of diagnostics.snapon.com/theprogram...
  • Page 10 24/7 at: Snap-on is a trademark, registered in the United States and other countries, of Snap-on Incorporated. All other marks are trademarks or registered trademarks of their respective holders. ©2018 Snap-on Incorporated. All pictures and illustrations shown are for reference purposes only.
