Blue-only mode convenient for monitoring
noise
All three CRT cathodes can be driven with a blue
signal, producing a monochrome display. This mode
is convenient for chroma and phase adjustment, and
for monitoring VTR noise.
Matrix selection
The ITU-601, ITU-709 and SMPTE-240M matrix
modes can be selected for individual input signals.
Beam landing correction circuit (BVM-
D24E1WU/D24E1WE/D24E1WA/D32E1WU/
D32E1WE/D32E1WA only)
The beam landing shift caused by the change in CRT
luminance and temperature, and that caused by the
earth's magnetism can be adjusted manually, or
automatically using the optional BKM-14L auto setup
probe.
Digital uniformity circuit (BVM-D24E1WU/
D24E1WE/D24E1WA/D32E1WU/D32E1WE/
D32E1WA only)
Uniform white can be reproduced on every point of the
screen, even in the peripheral area, thanks to the built-
in digital uniformity circuit. The uniformity can be
adjusted to match the installation conditions of the
monitor. Automatic adjustment is also possible using
the optional BKM-14L auto setup probe.
Digital convergence circuit (BVM-D32E1WU/
D32E1WE/D32E1WA only)
Clear color can be reproduced on every point of the
screen, even in the peripheral area, thanks to the built-
in digital convergence circuit. The convergence can be
adjusted to match the installation conditions of the
monitor.
Other features
• The monitor's various functions and operating
conditions can be set with on-screen menus.
• Compatible with the ISR (Interactive Status
Reporting) system.
• Has both RS-485 serial remote and relay contact
parallel remote control connectors.
• Built-in test signal generator for crosshatch, 100%
white signal, 20% gray signal, gray scale, and
PLUGE (Picture Line Up Generating Equipment).
• Built-in Caption Vision decoder.
• Pulse cross function for simultaneous checking of the
horizontal and vertical synchronization signals.
• Auto and manual degaussing.
• Built-in CRT protection circuit.
• The monitor may be mounted in an EIA-standard 19-
inch rack, using an optional BKM-30E20 Rack
Mount Kit (BVM-D20F1U/D20F1E/D20F1A only).
• The appearance of the monitor can be changed to
16:9 or 4:3 display by the replacement of a mask
(BVM-D20F1U/D20F1E/D20F1A only).

Options

For external control
BKM-10R Monitor Control Unit
BKM-11R Monitor Control Unit
A controller, allowing you to control multiple monitors
from one control unit.
BKM-12Y Monitor Memory Card
Memory cards which can be read and written by the
BKM-10R/11R.
BKM-14L Auto Setup Probe
A probe, allowing the automatic adjustment of this
monitor's color temperature.
For the BVM-D24E1WU/D24E1WE/D24E1WA/
D32E1WU/D32E1WE/D32E1WA, the probe is also
used for white uniformity adjustment.
For installation
BKM-30E20 Rack Mount Kit
Rack mount kit for mounting the BVM-D20F1U/
D20F1E/D20F1A in an EIA standard 19-inch rack.
BKM-32H Monitor Control Unit Attachment Kit
Assembly kit for attaching a BKM-10R Monitor
Control Unit to the BVM-D20F1U/D20F1E/D20F1A.
BKM-34H Monitor Control Unit Attachment Kit
Assembly kit for attaching a BKM-10R Monitor
Control Unit to the BVM-D24E1WU/D24E1WE/
D24E1WA.
5
