[C7]
Adjusting Beam Landing and Digital Uniformity (SET UP 7) — WHITE
UNIFORMITY Menu

Overview

The following two adjustments can be performed using
the WHITE UNIFORMITY menu, by making the
white in the picture as uniform as possible.
• Correcting the shift of beam landing caused by the
earth's magnetism (LANDING ADJUST menu)
• Adjusting the color unevenness of the CRT
(DIGITAL UNIFORMITY menu)

Structure of the WHITE UNIFORMITY Menu

Level 1
WHITE UNIFORMITY (1/2) C7
(LANDING ADJUST)
WHITE UNIFORMITY (2/2) C7
(DIGITAL UNIFORMITY ADJ)
INPUT CONFIGURATION C1
REMOTE C2
PASSWORD C3
SYSTEM CONFIGURATION C4
ON SCREEN SET C5
ALIGNMENT C6
WHITE UNIFORMITY C7
EXTEND MENU C8
(BVM-D24E1WU/D24E1WE/D24E1WA/D32E1WU/D32E1WE/D32E1WA only)
Note
Perform the digital uniformity adjustment after the
beam landing adjustment has been completed.
Level 2
Level 3
MANUAL C71
DIRECTION C711
FINE ADJUST C712
AUTO C72
SET PROBE ON CURSOR
C721
SIGNAL
EXT
INT
MANUAL C73
ADJUST C731
CURSOR H SIZE
CURSOR V SIZE
AUTO FULL POINTS C74
SET PROBE ON CURSOR
C741
AUTO ONE POINT C75
ORIGINAL VALUE
SIGNAL
EXT
INT
Level 4
NORTH
NORTH EAST
EAST
SOUTH EAST
SOUTH
SOUTH WEST
WEST
NORTH WEST
NS
TOP LEFT
TOP RIGHT
BOTTOM LEFT
BOTTOM RIGHT
RESET
1035/60
I
16:9–UNDER
B
G
R
51
