Nominal chromaticity coordinates:
SMPTE C phosphor (BVM-D32E1WU)
R
G
B
EBU phosphor (BVM-D32E1WE/
D32E1WA)
R
G
B
Error: ± 0.005 or less
Mass
BVM-D20F1U/D20F1E/D20F1A:
approx. 38 kg (83 lb 12 oz)
BVM-D24E1WU/D24E1WE/
D24E1WA: approx. 51 kg (112 lb 7 oz)
BVM-D32E1WU/D32E1WE/
D32E1WA: approx. 94 kg (427 lb 11
oz)
Power consumption
BVM-D20F1U/D20F1E/D20F1A:
155 W
When an optional adaptor is installed:
210 W
BVM-D24E1WU/D24E1WE/
D24E1WA: 150 W
When an optional adaptor is installed:
205 W
BVM-D32E1WU/D32E1WE/
D32E1WA: 180 W
When an optional adaptor is installed:
235 W
Power requirements
BVM-D20F1U/D20F1E/D20F1A: 100
to 240 V AC, 2.3 to 1.0 A, 50/60 Hz
BVM-D24E1WU/D24E1WE/
D24E1WA: 100 to 240 V AC, 2.1 to
0.9 A, 50/60 Hz
BVM-D32E1WU/D32E1WE/
D32E1WA: 100 to 240 V AC, 2.4 to
1.0 A, 50/60 Hz
Peak inrush current
(1) Power ON, current probe method:
47 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1
18 A (230 V)
x
y
0.630
0.340
0.310
0.595
0.155
0.070
x
y
0.640
0.330
0.290
0.600
0.150
0.060
Input/output connectors
Video input BNC type
3 (with loop-through
outputs)
G/B/R: Composite 1.0 Vp-p or non-
composite 0.7 Vp-p
Y: Composite 1.0 Vp-p or non-composite
0.7 Vp-p
P
/P
: Non-composite 0.7 Vp-p
B
R
Sync: ±0.3 V±6 dB, positive/negative, tri-
level sync, or 0.3 V±6 dB negative sync
Sync input BNC type
1 (with loop-through output)
0.3 to 8 Vp-p, positive/negative, tri-level
sync signal input, or 0.3 to 8 Vp-p,
negative sync signal input
Return loss More than 40 dB (10 MHz, with
75-ohm termination)
Remote control
OPTION: Mini-DIN 8-pin 1
CONTROL UNIT: D-sub 9-pin
REMOTE 1: D-sub 9-pin
through output), RS-485 serial
interface
REMOTE 2: D-sub 9-pin
ISR: D-sub 9-pin
Video signal
Differential gain
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Less than 5% (for luminance from 0 to
2
100 cd/m
)
BVM-D32E1WU/D32E1WE/
D32E1WA: Less than 5% (for luminance
from 0 to 70 cd/m
Differential phase
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Less than 5° (for luminance from 0 to
2
100 cd/m
)
BVM-D32E1WU/D32E1WE/
D32E1WA: Less than 5° (for luminance
from 0 to 70 cd/m
Frequency response
50 Hz to 30 MHz, +1 dB/ –3 dB
DC restoration
Back porch type
Black level fluctuation: less than 1% for
10 % to 90% APL input signal variation
1
1 (with loop-
1
1
2
)
2
)
63
