Specifications
Synchronization
Vertical blanking time
Less than 650 µs.
Horizontal blanking time
Less than 3.77 µs. (1080/60I, 1035/60I)
Picture performance
Normal scan
5% overscan of CRT effective screen area
(±10% of CRT effective screen area)
Underscan 3% underscan of CRT effective screen
area (±10% of CRT effective screen
area)
Linearity
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Within a central area bounded by a
circle with a diameter equal to the
picture height, less than 0.5 % of the
picture height, and outside the same
area, about 1 % of the picture height
(1080/60I, 1035/60I)
BVM-D32E1WU/D32E1WE/
D32E1WA: Within a central area
bounded by a circle with a diameter
equal to the picture height, less than 1
% of the picture height, and outside the
same area, about 2 % of the picture
height (1080/60I, 1035/60I)
Color temperature
D65, D93 (adjustable to other color
temperatures)
Convergence error
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Within a central area bounded by a
circle with a diameter equal to the
picture height.
Less than 0.4 mm with a central area
bounded by a circle and less than 0.7
mm at any other point.
BVM-D32E1WU/D32E1WE/
D32E1WA:
Within a central area bounded by a
circle with a diameter equal to the
picture height.
Less than 0.5 mm with a central area
bounded by a circle and less than 0.8
mm at any other point.
64
Standard luminescence
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
2
100 cd/m
(at standard 1 Vp-p 100%
white signal)
BVM-D32E1WU/D32E1WE/
D32E1WA: 70 cd/m
100% white signal)
Raster size stability
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Less than 1% of picture height (at 100
2
cd/m
peak luminescence, 10 to 90%
APL)
BVM-D32E1WU/D32E1WE/
D32E1WA: Less than 1% of picture
height (at 70 cd/m
10 to 90% APL)
Scan delay Horizontal: Approx.
Vertical: Approx.
Resolution BVM-D20F1U/D20F1E/D20F1A:
700 TV lines (16:9)
900 TV lines (4:3)
(at screen center, 100 cd/m
luminescence)
BVM-D24E1WU/D24E1WE/
D24E1WA:
1000 TV lines (16:9)
1000 TV lines (4:3)
(at screen center, 100 cd/m
luminescence)
BVM-D32E1WU/D32E1WE/
D32E1WA:
1000 TV lines (16:9)
1000 TV lines (4:3)
(at screen center, 70 cd/m
Operating conditions
Temperature
0°C to 35°C (32°F to 95°F)
Optimum temperature
20°C to 30°C (68°F to 86°F)
Humidity
0% to 90% (no condensation)
Pressure
700 hPa to 1060 hPa
2
(at standard 1 Vp-p
2
peak luminescence,
3
/
line
8
1
/
field
2
2
2
2
luminescence)
