[C4]
Setting the Channel Selection Method, Power-Up Conditions
and Decoder (SET UP 4) — SYSTEM CONFIGURATION Menu

Overview

The SYSTEM CONFIGURATION menu is used for
the following settings:
• Channel number entry method (INPUT SELECT

menu)

This menu sets the way in which the numeric keypad
can be used to enter channel numbers.
• Power-up condition (STANDBY MODE menu)
This menu sets the condition of the monitor when the
MAIN POWER switch on the rear panel is switched
on.
• Power-up input channel (DEFAULT CH menu)
This menu sets the power-up input channel.
• Time from power-up until degauss (DEGAUSS
DELAY menu)
If several monitors are turned on at the same time and
all start degaussing at the same time, there will be a
very large current draw on the power supply for a few
moments. To prevent this, the delay time between
power-up and degaussing can be set for each monitor
independently.

Structure of the SYSTEM CONFIGURATION Menu

Level 1
INPUT CONFIGURATION C1
REMOTE C2
PASSWORD C3
SYSTEM CONFIGURATION C4
ON SCREEN SET C5
ALIGNMENT C6
WHITE UNIFORMITY C7
EXTEND MENU C8
44
• Residual subcarrier detection (RESIDUAL SC
SW menu) (when using the BKM-24N/25P)
It is possible to detect residual subcarrier signals from
phase change by setting the decoder adpator's
residual subcarrier switch on.
• Auto color control (ACC SW menu) (when using
the BKM-27T)
Selects if the ACC (Auto Color Control) circuit is
activated or deactivated.
• Setting of the contrast and brightness after
adjusting the white balance (CONT/BRT HOLD
menu)
Selects if the adjusted contrast and brightness are
retained or they are reset to the center values.
• Assigning shortcut to the COLOR TEMP ADJ
menu to the [F2] key (COL TEMP SHORT-CUT
menu)
Assigns the shortcut to the MANUAL menu of the
COLOR TEMP ADJ menu to the [F2] key. This
allows you to jump directly to the MANUAL menu
corresponding to the color temperature set to the
currently displayed image (STD/COL 1/COL 2/CH
SET).
Level 2
INPUT SELECT
STANDBY MODE
DEFAULT CH
DEGAUSS DELAY
RESIDUAL SC SW
ACC SW
CONT/BRT HOLD
COL TEMP SHORT-CUT
