Connection Cable Specifications for Color Temperature Probes

Special cables are required to connect color
temperature probes other than the Sony BKM-14L to
the monitor.
Connection cable for GRASEBY SLS 9400 probe
Connection cable for MINOLTA CA-100 probe
The following diagrams show specifications and pin
assignments for the required cables.
Modular connector
1
6
Signal
Pin Number
N.C.
1
2
GND
3
RXD
4
TXD
5
GND
6
N.C.
D-sub 25-pin connector
(male)
1
13
14
25
Signal
Pin Number
1
N.C.
2
TXD
3
RXD
4
RTS
5
CTS
6
N.C.
GND
7
8 to 25
N.C.
Mini DIN 8-pin connector
(male)
1
2
5
3
6
8
Signal
Pin Number
1
NC
2
NC
3
RTS
4
GND
5
N.C.
6
TXD
7
+5V
8
RXD
Mini DIN 8-pin connector
(male)
1
2
5
3
8
6
Signal
Pin Number
1
NC
2
NC
3
RTS
4
GND
5
N.C.
6
TXD
7
+5V
8
RXD
69
