Functional Principle, Technical Data
combiSENSOR
2.3

Technical Data

Sensor
Measuring range (max. offset)
Insulator thickness
Min. diameter target
Ground electrode
1
Linearity ±0.05 %
Resolution
Bandwidth
2
Sensor temperature stability,
capacitive
Sensor temperature stability,
eddy current
3
Controller temperature stability
sensor
Operation
sensor cable
temperature
controller
sensor, cable
Storage
temperature
controller
analog
Output
digital
Versorgung
Protection class
sensor
Weight
controller
The quoted data apply to films with e
1) Reference material of ground electrode: Stainless steel (1.4571) or aluminum. Changes at
the ground electrode (material or shape) require rebalancing of the sensor and the control-
ler by the manufacturer.
2) Only applies in conjunction with controller KSS6380, e
3) Valid in the range of +10 °C up to +60 °C.
4) Only applies at a sampling rate in a case of 1040 Hz.
KSH5
5 mm (.20)
2 mm max. (.08)
45 mm (1.77)
Even surface or min. diameter 200 mm (7.88)
±2.5 µm
with start of measuring range
2.5 mm
0.32 µm
analog: 500 Hz (-3 dB) ; digital:1040, 520, 104, 26 samples
4
± 50 ppm/°C
± 50 ppm/°C
max. 50 ppm/°C
-10 ... +85 °C (+14 ... +185 °F)
-10 ... +125 °C (+14 ... +257 °F)
+10 ... +60 °C (+50 ... +140 °F)
-10 ... +100 °C (+14 ... +212 °F)
0 ... +75 °C (+32 ... +167 °F)
capacitive, eddy current and differential signal: 0 ... +10 V
(10 mA max. / short circuit proof);
internal sensor temperature signal (not scaled)
Ethernet 24 bit (capacitive, eddy current, differential and internal
temperature signal (not scaled))
9 ... 36 V (@24 V:0.25 A)
IP 40 (controller)
IP 54 (sensor)
1100 g
= 2 ... 5 and at a temperature of 20 °C.
r
r
with start of measuring range
4.5 mm
0.62 µm
80 g
of insulating target constant.
