Installation (Wiring Diagrams, Fuse Selection & Vehicle Wiring Reference Charts); Type 1 - Directed DS4+ Installation Manual

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
ENGINE
START
STOP
Autolight:
Pink, pin 8
White Conn.
(at Main Body ECU)
9
Black PTS Button Conn.
(at PTS switch)
Black
5 4 3 2 1
Connector
10 9 8 7 6
Black Steering Lock conn.
(at steering lock conn.)
(-) PTS:
Gray, pin 5
CUT
20 22 23 27 29
8 10 12 13 14 15 16 17 18
2 5
(-) Lock:
Blue, pin 29
(-) Unlock: Lt. Green, pin 2
HS CAN High:
White, pin 6
1 8
9 16
(-) SLP: Red, pin 4
HS CAN Low:
Black, pin 14
(-) SLP Output: Lt. Green/Black: 1
(-) Lock Output: Dk. Green/Black: 3
(-) Unlock Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
Siren
Hood Pin
Autolight Interrupt (conn. side): Blue/White: 1
Autolight Interrupt (veh. side): Blue: 3
12
36 27
26
11
34 25
33 24 10
32 23
9
31 22
8
30 21
29 20
7
28 19
White Conn.
(at Main Body ECU)
18 6
17 5
16 4
15 3
14 2
(+) 12V:
Blue, pin 13
13 1
Diagnostic
Conn. OBDII
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-08-23 Directed. All rights reserved.
).
DS4
DS4
DS4+
DS4+ TL8
