Locating Steering Lock Connector in Vehicle
1. To gain access to the SLP connector, remove metal clip to remove the white plastic housing.
Steering Lock Connector
Steering Lock Connector
2. Move the white plastic housing over enough to access the SLP connector.
18
1. Remove
metal clip
1. Remove
metal clip
Steering Lock
connector
Steering Lock
connector
2. Remove white
plastic housing
2. Remove white
plastic housing
DS4+ TL8
© 2017-08-23 Directed. All rights reserved.
