Type 3 - Directed DS4+ Installation Manual

Type 3

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
Black PTS Button Conn.
Black
ENGINE
START
STOP Connector
Autolight:
CUT
Black or White,
pin 8
20 22 23
White Conn.
8 10
(at Dash Fuse Box)
2
(-) Unlock: Pin 2
16
(-) SLP:
Lt. Green or Tan,
pin 4
(at PTS switch)
5 4 3 2 1
10 9 8 7 6
Black Steering Lock conn.
(at steering lock conn.)
(-) PTS:
Yellow or Tan,
pin 5
27 29
12 13 14 15 16 17 18
5
(-) Lock: Pin 29
HS CAN High:
Violet or Lt. Blue, pin 6
1 8
9 16
HS CAN Low:
White,
pin 14
(-) SLP Output: Lt. Green/Black: 1
(-) Lock Output: Dk. Green/Black: 3
(-) Unlock Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
Autolight Interrupt (conn. side): Blue/White: 1
Autolight Interrupt (vehicle side): Blue: 3
White Conn.
1
(at Main Body ECU)
(+)12V:
Green or Black, pin 1
Diagnostic
Conn. OBDII
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
).
DS4
DS4
DS4+
DS4+ TL8
