Type 2 - Directed DS4+ Installation Manual

Type 2

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
ENGINE
START
STOP Connector
Autolight:
CUT
Green, pin 8
20 22 23
White Conn.
8 10 12 13 14 15 16
(at Dash Fuse Box)
2
(-) Unlock: Lt. Green, pin 2
13
Black PTS Button Conn.
(at PTS switch)
Black
5 4 3 2 1
10 9 8 7 6
(-) PTS:
Lt. Green, pin 5
Black Steering Lock conn.
(at steering lock conn.)
27 29
17 18
5
(-) Lock: Red, pin 29
Dash
Fuse Box
HS CAN High:
Black, pin 6
1 8
9 16
HS CAN Low:
(-) SLP: Yellow,
White, pin 14
pin 4
(-) SLP Output: Lt. Green/Black: 1
(-) Lock Output: Dk. Green/Black: 3
(-) Unlock Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
Siren
Hood Pin
Autolight Interrupt (conn. side): Blue/White: 1
Autolight Interrupt (vehicle side): Blue: 3
White Conn.
(at Dash Fuse Box)
1
11 26
12 27
2
13 28
3 14 29
15 30
4
16 31
5
17 32 (+) 12V:
18 33
Red, pin 6
6
19 34
7 20 35
21 36
8
22 37
9 23 38
24 39
10
25 40
Diagnostic
Conn. OBDII
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
).
DS4
DS4
DS4+
DS4+ TL8
