Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

Refer to "Pre-installation and application warnings" on page 4 and "Vehicle wiring reference chart" on page 9 for important information on this installation.
i84
(Gray conn. at BCM,
right of steering column)
8 7 6 5 4 3 2 1
23 22 21 20 9
19 18 17 16 15 14 13 12 11 10
33 27 26
35 34 32 31 30 29 28 25 24
FT CAN Low:
(-) Security Light: FT CAN High:
Brown/Red, pin 33 Pink, pin 27 Violet, pin 26
CUT
87
86 85
(+) 12V
87a
30
(+) Keysense: Red or
Black/White, pin 7
(+) Brake: Brown/Red
or Brown/White, pin 23
7
6 5 4 3 2 1
19 18 17 16 15 14 13 12 11 10 9 8
28 27 26 25 24 23 22 21 20
B281
(White conn. at BCM,
right of steering column)
B69
(+) 12V
(White conn. at
2 1
parking light on
4
3
steering column)
86 87
87a
(+) Parking Lights:
30
Orange, pin 4
8
Keyless Data:
HS CAN High:
Yellow/Green, pin 9
Red, pin 20
HS CAN Low:
Blue, pin 30
Immobilizer Data 2:
Black/Pink, pin 28
CUT
85
B72
(White conn.
at Ignition Switch)
3 2 1
6 5 4
Refer to the Vehicle Wiring Reference Chart
on pages 9-10 for wire colors and location.
B280
(White conn. at BCM,
right of steering column)
7 6 5 4 3 2 1
18
20 19 17 16 15 14 13 12 11 10 9 8
28
30 29 27 26 25 24 23 22 21
Immobilizer Data 1: White/Blue, pin 18
CUT CUT
Keyless Data (conn. side): Yellow/Black: 8
(-) Security Light Output: Lt.Green/Black: 1
(-) Parking Light Output: Lt.Blue/Black: 10
Siren
Hood Pin
Keyless Data Interr. (conn.side): Blue/White: 1
Immo. Data Interr. (conn.
Immo. Data Interr. (vehicle
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
Immo. Data (veh. side): Orange/Black: 7
(+) Keysense Output: White: 7
(+) Siren Output: Brown/Red: 11
(+) Brake Input: Brown: 14
(+) Keysense Input: Orange/Black: 18
(-) Hood Input: Gray: 21
Keyless Data Interr. (veh. side): Blue: 3
(+) 12V: Red: 6 & 12
side): Lt. Green: 8
side): Lt. Green/White: 9
(-) Ground: Black: 10
(+) 12V Input: Red/Black: 2
(+) Ignition 2: Pink/White: 4
(+) 12V Input: Red: 5
Starter Input (key side): Green: 6
(+) Starter Output (veh. side): Violet: 7
(+) Accessory Output: Orange: 8
(+) 12V Input: Red/White: 9
(+) Ignition Input/Ouput: Pink: 10
It is important to check that the
fuses are positioned correctly. See
Fuse selection on the next page for
more information.
