Directed DS4+ Installation Manual page 11

Wire Information
Function
Lexus IS 350 (Smart key) 2014-2016
SLP
PTS
HS CAN High
HS CAN Low
Autolight
Lock
Unlock
12V
Lexus RC350 (Smart Key) 2015-2016
SLP
PTS
HS CAN High
HS CAN Low
Autolight
Lock
Unlock
12V
Lexus RC F (Smart Key) 2015
SLP
PTS
HS CAN High
HS CAN Low
Autolight
Lock
Unlock
12V
11
Color Pin Polarity
Red 4 (-)
Gray 5 (-)
White 6 Data
Black 14 Data
Pink 8 Cut
Blue 29 (-)
Lt. Green 2 (-)
Blue 13 (+)
Red 4 (-)
Gray 5 (-)
White 6 Data
Black 14 Data
Pink 8 Cut
Blue 29 (-)
Lt. Green 2 (-)
Blue 13 (+)
Red 4 (-)
Gray 5 (-)
White 6 Data
Black 14 Data
Pink 8 Cut
Blue 29 (-)
Lt. Green 2 (-)
Blue 13 (+)
Connector Information
Location
Steering lock connector.
Engine start/stop switch.
OBDII.
OBDII.
Main body ECU.
Main body ECU.
Main body ECU.
Main body ECU.
Steering lock connector.
Engine start/stop switch.
OBDII.
OBDII.
Main body ECU.
Main body ECU.
Main body ECU.
Dash fuse box.
Steering lock connector.
Engine start/stop switch.
OBDII.
OBDII.
Main body ECU.
Main body ECU.
Main body ECU.
Dash fuse box.
Color Pins Ref.
Black 7 A
Black 10 B
White 16 C
White 16 C
White 30 D
White 30 D
White 30 D
White 36 E
Black 7 A
Black 10 B
White 16 C
White 16 C
White 30 D
White 30 D
White 30 D
White 36 E
Black 7 A
Black 10 B
White 16 C
White 16 C
White 30 D
White 30 D
White 30 D
White 36 E
DS4+ TL8
