Installation (Wiring Diagrams, Fuse Selection & Vehicle Wiring Reference Charts); Type 1 With T-Harness (Thfon1); Type 1 - Directed DS4+ Installation Manual

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

with T-Harness (THFON1)
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
Ignition Switch
Connector
(connector side)
1
1 2 3 4 5 6 7 2
male
female
OBDII
Diagnostic 16-pin Connector
8
Ignition
Barrel
4 7
3 5 6
Refer to the Vehicle wiring
reference charts for wire and
connector details related to
the standard connections in
the vehicle.
P.A.T.S.
4-pin Connector
(connector side)
THFON1
(optional T-Harness)
(AC) Tach Output: Violet/White
(-) Lock Output: Green/Black
(-) Trunk Hatch Release/Power Liftgate Output: Red/White
(-) Unlock Output: Blue/Black
(+) Siren Output: Brown/Red
Hood Pin
Siren
Hood Pin: Gray
(+) Parking Light Output: White
RAP Off Interrupt: Lt. Green
Cut
RAP Off Interrupt: Lt. Green/White
Driver Door Trigger
).
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
It is important to check that the
fuses are positioned correctly.
DS4+ FORD6
